Set to true in order to override the default behavior in which series do not animate if an axis range changes.


        //Initialize
        $(".selector").igDataChart({
            animateSeriesWhenAxisRangeChanges: true
        });

        //Get
        var animate= $(".selector").igDataChart("option", "animateSeriesWhenAxisRangeChanges");

        //Set
        $(".selector").igDataChart("option", "animateSeriesWhenAxisRangeChanges", true);

Sets or gets the automatic height to add when automatically adding margins to the chart.


        //Initialize
        $(".selector").igDataChart({
            autoMarginHeight : 100
        });

        //Get
        var height = $(".selector").igDataChart("option", "autoMarginHeight");

        //Set
        $(".selector").igDataChart("option", "autoMarginHeight", 100);

Sets or gets the automatic width to add when automatically adding margins to the chart.


        //Initialize
        $(".selector").igDataChart({
            autoMarginWidth : 200
        });

        //Get
        var width = $(".selector").igDataChart("option", "autoMarginWidth");

        //Set
        $(".selector").igDataChart("option", "autoMarginWidth", 200);


An array of axis objects.

var data = [{ "Label": "2009", "Item1": "Value1", "Item2": 1000, "Item3": 1019.75},
			{ "Label": "2010", "Item1": "Value2", "Item2": 1500, "Item3": 1180.25},
			{ "Label": "2011", "Item1": "Value3", "Item2": 1200, "Item3": 1205.55},
			{ "Label": "2012", "Item1": "Value4", "Item2": 1450, "Item3": 1144.65}];

//    Initialization
$(".selector").igDataChart({
        axes: [{
            name: "xAxis",
            type: "categoryX",
            dataSource: data,
            label: "Label"
        },
        {
            name: "yAxis",
            type: "numericY"
        }]
    });

//    Get
var axes = $(".selector").igDataChart("option", "axes");
axes[0];  // access 'xAxis' options
axes[1];  // access 'yAxis' options

//    Set
$(".selector").igDataChart("option", "axes",
        [{
            name: "xAxis",
            type: "categoryX",
            dataSource: data,
            label: "Label",
            labelVisibility: "collapsed"
        },
        {
            name: "yAxis",
            type: "numericY",
            labelVisibility: "collapsed"
        }]
    );


• coercionMethods

  Type:

  object

  Default:

  null

  Gets or sets the coercion methods to use when loading data from data sources.
  Should be specified before setting any member paths, if being used. Setting it later
  will not cause data to be reimported into the chart.

  Code Sample

  var data = [
        { "Date": new Date(2011, 1, 1), "Value": 1000 },
        { "Date": new Date(2011, 1, 2), "Value": 995 },
        { "Date": new Date(2011, 1, 3), "Value": 925.5 },
        { "Date": new Date(2011, 1, 4), "Value": 940.25 },
        { "Date": new Date(2011, 1, 5), "Value": 1020.5 }
    ];

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryDateTimeX",
              dataSource: data,
              dateTimeMemberPath: "Date!parseDate",
              coercionMethods: {
                  parseDate: function (val) {
                      var newVal = new Date(val);
                      newVal.setDate(newVal.getDate() + 4);
                      return newVal;
                  }
              }
          }]
      });


• crossingAxis

  Type:

  string

  Default:

  null

  Gets or sets the CrossingAxis property.

  Code Sample

  var data = [{ "Label": "2009", "Item1": "Value1", "Item2": 1000, "Item3": 1019.75},
  			{ "Label": "2010", "Item1": "Value2", "Item2": 1500, "Item3": 1180.25},
  			{ "Label": "2011", "Item1": "Value3", "Item2": 1200, "Item3": 1205.55},
  			{ "Label": "2012", "Item1": "Value4", "Item2": 1450, "Item3": 1144.65}];
  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY",
              crossingAxis: "xAxis",
              crossingValue: 700
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[1].crossingAxis;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY",
              crossingAxis: "xAxis",
              crossingValue: 700
          }]
      );


• crossingValue

  Type:

  object

  Default:

  null

  Gets or sets the CrossingValue property.

  Code Sample

  var data = [{ "Label": "2009", "Item1": "Value1", "Item2": 1000, "Item3": 1019.75},
  			{ "Label": "2010", "Item1": "Value2", "Item2": 1500, "Item3": 1180.25},
  			{ "Label": "2011", "Item1": "Value3", "Item2": 1200, "Item3": 1205.55},
  			{ "Label": "2012", "Item1": "Value4", "Item2": 1450, "Item3": 1144.65}];
  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY",
              crossingAxis: "xAxis",
              crossingValue: 700
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[1].crossingValue;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY",
              crossingAxis: "xAxis",
              crossingValue: 700
          }]
      );


• dataSource

  Type:

  object

  Default:

  null

  Can be any valid data source accepted by $.ig.DataSource, or an instance of an $.ig.DataSource itself.

  Code Sample

  var data = [{ "Label": "2009", "Item1": "Value1", "Item2": 1000, "Item3": 1019.75},
  			{ "Label": "2010", "Item1": "Value2", "Item2": 1500, "Item3": 1180.25},
  			{ "Label": "2011", "Item1": "Value3", "Item2": 1200, "Item3": 1205.55},
  			{ "Label": "2012", "Item1": "Value4", "Item2": 1450, "Item3": 1144.65}];
  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].dataSource;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }]
      );


• dataSourceType

  Type:

  string

  Default:

  null

  Explicitly set data source type (such as "json"). Please refer to the documentation of $.ig.DataSource and its type property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              dataSourceType: "json"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].dataSourceType;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              dataSourceType: "json"
          }]
      );


• dataSourceUrl

  Type:

  string

  Default:

  null

  Specifies a remote URL accepted by $.ig.DataSource in order to request data from it.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSourceUrl: "http://www.example.com/chart-data"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].dataSourceUrl;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryX",
              dataSourceUrl: "http://www.example.com/chart-data"
          }]
      );


• dateTimeMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the DateTime mapping property for the CategoryDateTimeXAxis.

  Code Sample

  var data = [
        { "Date": new Date(2011, 1, 1), "Value": 1000 },
        { "Date": new Date(2011, 1, 2), "Value": 995 },
        { "Date": new Date(2011, 1, 3), "Value": 925.5 },
        { "Date": new Date(2011, 1, 4), "Value": 940.25 },
        { "Date": new Date(2011, 1, 5), "Value": 1020.5 }
    ];

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryDateTimeX",
              dataSource: data,
              dateTimeMemberPath: "Date"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].dateTimeMemberPath;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryDateTimeX",
              dataSource: data,
              dateTimeMemberPath: "Date"
          }]
      );


• displayType

  Type:

  enumeration

  Default:

  null

  Gets or sets the axis display type. Continuous display type divides the axis into even intervals, where labels will not necessarily be aligned with data points. Discrete display type will not use a constant interval, but will align each label with its data point.

  Members

  • continuous
  • Type:string
  • Points occur at even intervals, even where data is not present at a given point.
  • discrete
  • Type:string
  • Points occur when data is present, possibly at uneven intervals.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              displayType: "continuous"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].displayType;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              displayType: "continuous"
          }]
      );


• enhancedIntervalMinimumCharacters

  Type:

  number

  Default:

  5

  Gets or sets the mininum desired characters to be displayed for horizontal axes when using advanced label heuristics. -1 will attempt to adjust the interval to precisely fit the horizontal labels.

• formatLabel

  Type:

  object

  Default:

  null

  Sets or gets a function which takes an object that produces a formatted label for displaying in the chart.

  Code Sample

  var data = [
        { "Date": new Date(2011, 1, 1), "Value": 1000 },
        { "Date": new Date(2011, 1, 2), "Value": 995 },
        { "Date": new Date(2011, 1, 3), "Value": 925.5 },
        { "Date": new Date(2011, 1, 4), "Value": 940.25 },
        { "Date": new Date(2011, 1, 5), "Value": 1020.5 }
    ];

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryDateTimeX",
              dataSource: data,
              label: "Date",
              formatLabel: function (item) {
                  var ret = '';
                  ret += item.getFullYear();
                  ret += "/";
                  ret += item.getMonth() + 1;
                  ret += "/";
                  ret += item.getDate();
                  return ret;
              }
          }]
      });


• gap

  Type:

  number

  Default:

  0

  Gets or sets the amount of space between adjacent categories for the current axis object.
  The gap is silently clamped to the range [0, 1] when used.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              gap: 10
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].gap;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              gap: 10
          }]
      );


• innerRadiusExtentScale

  Type:

  number

  Default:

  0

  Defines the percentage of the maximum radius extent to leave blank at the center of the chart. Should be
  a value between 0.0 and 1.0.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              innerRadiusExtentScale: 0.15
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].innerRadiusExtentScale;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              innerRadiusExtentScale: 0.15
          }]
      );


• interval

  Type:

  number

  Default:

  0

  Gets or sets the frequency of displayed labels.
  The set value is a factor that determines which labels will be hidden. For example, an interval of 2 will display every other label.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              interval: 2
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].interval;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              interval: 2
          }]
      );


• isDataPreSorted

  Type:

  bool

  Default:

  false

  Gets or sets whether the data assigned to the date time axis should be considered pre-sorted by date/time.

• isInverted

  Type:

  bool

  Default:

  false

  Gets or sets the IsInverted property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              isInverted: true
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].isInverted;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              isInverted: true
          }]
      );


• isLogarithmic

  Type:

  bool

  Default:

  false

  Gets or sets the IsLogarithmic property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              isLogarithmic: true
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].isLogarithmic;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              isLogarithmic: true
          }]
      );


• label

  Type:

  object

  Default:

  null

  Gets or sets the axis label format string.

  Code Sample

  var data = [{ "Label": "2009", "Item1": "Value1", "Item2": 1000, "Item3": 1019.75},
  			{ "Label": "2010", "Item1": "Value2", "Item2": 1500, "Item3": 1180.25},
  			{ "Label": "2011", "Item1": "Value3", "Item2": 1200, "Item3": 1205.55},
  			{ "Label": "2012", "Item1": "Value4", "Item2": 1450, "Item3": 1144.65}];
  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].label;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          }]
      );


• labelAngle

  Type:

  number

  Default:

  0

  Specifies the angle that labels on the axis should be rotated.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelAngle: 30
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelAngle;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              labelAngle: 30
          }]
      );


• labelBottomMargin

  Type:

  number

  Default:

  0

  The bottom margin to use for the labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelBottomMargin: 10
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelBottomMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              labelBottomMargin: 10
          }]
      );


• labelExtent

  Type:

  number

  Default:

  null

  Specifies the extent of the area dedicated to the labels for this axis. If unspecified, this value is auto-calculated.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelExtent: 10
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelExtent;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              labelExtent: 10
          }]
      );


• labelHorizontalAlignment

  Type:

  enumeration

  Default:

  right

  the horizontal alignment to use for the labels. Only applicable to vertical axes.

  Members

  • left
  • Type:string
  • left aligns the labels.
  • center
  • Type:string
  • center aligns the labels.
  • right
  • Type:string
  • right aligns the labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "yAxis",
              type: "numericY",
              labelHorizontalAlignment: "right"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelHorizontalAlignment;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              labelHorizontalAlignment: "right"
          }]
      );


• labelLeftMargin

  Type:

  number

  Default:

  0

  The left margin to use for the labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelLeftMargin: 10
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelLeftMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              labelLeftMargin: 10
          }]
      );


• labelLocation

  Type:

  enumeration

  Default:

  null

  Specifies the location to display the axis labels for this axis.

  Members

  • outsideTop
  • Type:string
  • The labels should have an outside top position.
  • outsideBottom
  • Type:string
  • The labels should have an outside bottom position.
  • outsideLeft
  • Type:string
  • The labels should have an outside left position.
  • outsideRight
  • Type:string
  • The labels should have an outside right position.
  • insideTop
  • Type:string
  • The labels should have an inside top position.
  • insideBottom
  • Type:string
  • The labels should have an inside bottom position.
  • insideLeft
  • Type:string
  • The labels should have an inside left position.
  • insideRight
  • Type:string
  • The labels should have an inside right position.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelLocation: "outsideBottom"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelLocation;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              labelLocation: "outsideBottom"
          }]
      );


• labelMargin

  Type:

  number

  Default:

  0

  The margin to use for the labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelMargin: 5
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              labelMargin: 5
          }]
      );


• labelRightMargin

  Type:

  number

  Default:

  0

  The right margin to use for the labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelRightMargin: 10
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelRightMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              labelRightMargin: 10
          }]
      );


• labelTextColor

  Type:

  string

  Default:

  null

  Overrides the color of the text used for the axis labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelTextColor: "blue"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelTextColor;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              labelTextColor: "blue"
          }]
      );


• labelTextStyle

  Type:

  string

  Default:

  null

  Overrides the style of the text used for the axis labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelTextStyle: "8pt Helvetica, Arial, sans-serif"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelTextStyle;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              labelTextStyle: "8pt Helvetica, Arial, sans-serif"
          }]
      );


• labelTopMargin

  Type:

  number

  Default:

  0

  The top margin to use for the labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelTopMargin: 10
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelTopMargin;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              labelTopMargin: 10
          }]
      );


• labelVerticalAlignment

  Type:

  enumeration

  Default:

  top

  the vertical alignment to use for the labels. Only applicable to horizontal axes.

  Members

  • top
  • Type:string
  • top aligns the labels.
  • center
  • Type:string
  • center aligns the labels.
  • bottom
  • Type:string
  • bottom aligns the labels.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelVerticalAlignment: "center"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelVerticalAlignment;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              labelVerticalAlignment: "center"
          }]
      );


• labelVisibility

  Type:

  enumeration

  Default:

  visible

  Specifies whether the labels are visible.

  Members

  • visible
  • Type:string
  • The labels should be visisble for this axis.
  • collapsed
  • Type:string
  • The labels should not be visible for this axis.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              labelVisibility: "collapsed"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].labelVisibility;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              labelVisibility: "collapsed"
          }]
      );


• logarithmBase

  Type:

  number

  Default:

  10

  Gets or sets the LogarithmBase property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              logarithmBase: 2
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].logarithmBase;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              logarithmBase: 2
          }]
      );


• majorStroke

  Type:

  string

  Default:

  null

  Gets or sets the MajorStroke property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              majorStroke: "blue"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].majorStroke;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              majorStroke: "blue"
          }]
      );


• majorStrokeThickness

  Type:

  number

  Default:

  1

  Gets or sets the MajorStrokeThickness property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              majorStrokeThickness: 5
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].majorStrokeThickness;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              majorStrokeThickness: 5
          }]
      );


• maximumValue

  Type:

  enumeration

  Default:

  0

  Gets or sets the axis MaximumValue.

  Members

  • number
  • Type:number
  • The maximum value can be set to be a number when the axis is of numeric type.
  • date
  • Type:date
  • The maximum value can be set to be a date object when type option is set to "categoryDateTimeX".

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              maximumValue: 1500
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].maximumValue;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              maximumValue: 1500
          }]
      );


• minimumValue

  Type:

  enumeration

  Default:

  0

  Gets or sets the axis MinimumValue.

  Members

  • number
  • Type:number
  • The minimum value can be set to be a number when the axis is of numeric type.
  • date
  • Type:date
  • The minimum value can be set to be a date object when type option is set to "categoryDateTimeX".

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              minimumValue: 500
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].minimumValue;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              minimumValue: 500
          }]
      );


• minorStroke

  Type:

  string

  Default:

  null

  Gets or sets the MinorStroke property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              minorStroke: "grey"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].minorStroke;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              minorStroke: "grey"
          }]
      );


• minorStrokeThickness

  Type:

  number

  Default:

  1

  Gets or sets the MinorStrokeThickness property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              minorStrokeThickness: 2
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].minorStrokeThickness;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              minorStrokeThickness: 2
          }]
      );


• name

  Type:

  string

  Default:

  null

  The unique identifier of the axis.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].name;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX"
          }]
      );


• overlap

  Type:

  number

  Default:

  0

  Gets or sets the amount of overlap between adjacent categories for the current axis object.
  The overlap is silently clamped to the range [-1, 1] when used.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              overlap: 0.5
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].overlap;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              overlap: 0.5
          }]
      );


• radiusExtentScale

  Type:

  number

  Default:

  0.75

  Defines the percentage of the maximum radius extent to use as the maximum radius. Should be
  a value between 0.0 and 1.0.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              radiusExtentScale: 0.5
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].radiusExtentScale;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              radiusExtentScale: 0.5
          }]
      );


• referenceValue

  Type:

  number

  Default:

  0

  Gets or sets the ReferenceValue property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              referenceValue: 0.5
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].referenceValue;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              referenceValue: 0.5
          }]
      );


• remove

  Type:

  bool

  Default:

  false

  Set to true in order to have an existing axis removed from the chart, by name.

  Code Sample

  //Set
  $(".selector").igDataChart("option", "axes",
    [{
      name: "xAxis",
      remove: true
    }]
  );


• responseDataKey

  Type:

  string

  Default:

  null

  See $.ig.DataSource. Specifies the name of the property in which data records are held if the response is wrapped.

  Code Sample

  var data = { "Records":
                [{ "Label": "2009", "Item1": "Value1", "Item2": 1000, "Item3": 1019.75},
  			  { "Label": "2010", "Item1": "Value2", "Item2": 1500, "Item3": 1180.25},
  			  { "Label": "2011", "Item1": "Value3", "Item2": 1200, "Item3": 1205.55},
  			  { "Label": "2012", "Item1": "Value4", "Item2": 1450, "Item3": 1144.65}]
            };

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              responseDataKey: "Records"
          },
          {
              name: "yAxis",
              type: "numericY"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].responseDataKey;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              responseDataKey: "Records"
          }]
      );


• showFirstLabel

  Type:

  bool

  Default:

  true

  Sets whether or not to show the first label on the axis.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              showFirstLabel: false
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].showFirstLabel;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              showFirstLabel: false
          }]
      );


• startAngleOffset

  Type:

  number

  Default:

  0

  Indicates the angle in degress that the chart's 0th angle should be offset.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              startAngleOffset: 30
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].startAngleOffset;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              startAngleOffset: 30
          }]
      );


• strip

  Type:

  string

  Default:

  null

  Gets or sets the Strip property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              strip: "grey"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].strip;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              strip: "grey"
          }]
      );


• stroke

  Type:

  string

  Default:

  null

  Gets or sets the Stroke property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              stroke: "blue"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].stroke;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX",
              stroke: "blue"
          }]
      );


• strokeThickness

  Type:

  number

  Default:

  1

  Gets or sets the StrokeThickness property.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              strokeThickness: 5
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].strokeThickness;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              strokeThickness: 5
          }]
      );


• tickLength

  Type:

  number

  Default:

  0

  The length of the tickmarks to display for this axis.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              tickLength: 5
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].tickLength;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              tickLength: 5
          }]
      );


• tickStroke

  Type:

  object

  Default:

  black

  The color to use for the tickmarks.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              tickStroke: "blue"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].tickStroke;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              tickStroke: "blue"
          }]
      );


• tickStrokeThickness

  Type:

  number

  Default:

  0.5

  The stroke thickness to use for the tickmarks.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              tickStrokeThickness: 2
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].tickStrokeThickness;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              tickStrokeThickness: 2
          }]
      );


• title

  Type:

  string

  Default:

  null

  The title to display for the component.

  Code Sample


            //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].title;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years"
          }]
      );


• titleAngle

  Type:

  number

  Default:

  0

  The angle to use for the axis title.

  Code Sample


  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleAngle: 90
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleAngle;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleAngle: 90
          }]
      );

• titleBottomMargin

  Type:

  number

  Default:

  0

  The bottom margin to use for the title.

  Code Sample


  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleBottomMargin:20
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleBottomMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleBottomMargin: 20
          }]
      );

• titleHorizontalAlignment

  Type:

  enumeration

  Default:

  center

  the horizontal alignment to use for the title.

  Members

  • left
  • Type:string
  • left aligns the title.
  • center
  • Type:string
  • center aligns the title.
  • right
  • Type:string
  • right aligns the title.

  Code Sample


            //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleHorizontalAlignment: "left"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleHorizontalAlignment;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleHorizontalAlignment: "left"
          }]
      );

• titleLeftMargin

  Type:

  number

  Default:

  0

  The left margin to use for the title.

  Code Sample


            //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleLeftMargin: 20
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleLeftMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleLeftMargin: 20
          }]
      );

• titleMargin

  Type:

  number

  Default:

  0

  The margin to display around the title of the axis.

  Code Sample


             //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleMargin: {top:20 , bottom:40, left:45, right:23}
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleMargin: {top:20 , bottom:40, left:45, right:23}
          }]
      );


• titlePosition

  Type:

  enumeration

  Default:

  auto

  the position to use for the title.

  Members

  • auto
  • Type:string
  • the title is positioned automatically.
  • left
  • Type:string
  • the title is positioned on the left of the labels, if applicable.
  • right
  • Type:string
  • the title is positioned on the right of the labels, if applicable.
  • top
  • Type:string
  • the title is positioned on the top of the labels, if applicable.
  • bottom
  • Type:string
  • the title is positioned on the bottom of the labels, if applicable.

  Code Sample


             //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titlePosition: "top"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titlePosition;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titlePosition: "top"
          }]
      );


• titleRightMargin

  Type:

  number

  Default:

  0

  The right margin to use for the title.

  Code Sample


              //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleRightMargin: 20
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleRightMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleRightMargin: 20
          }]
      );


• titleTextStyle

  Type:

  string

  Default:

  null

  The css font property to use for the title.

  Code Sample


             //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleTextStyle: "26pt Times New Roman|Georgia|Serif"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleTextStyle;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleTextStyle: "26pt Times New Roman|Georgia|Serif"
          }]
      );


• titleTopMargin

  Type:

  number

  Default:

  0

  The top margin to use for the title.

  Code Sample


             //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleTopMargin: 20
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleTopMargin;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleTopMargin: 20
          }]
      );


• titleVerticalAlignment

  Type:

  enumeration

  Default:

  center

  the vertical alignment to use for the title.

  Members

  • center
  • Type:string
  • center aligns the title.

  Code Sample


             //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleVerticalAlignment: "center"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].titleVerticalAlignment;

  //    Set
  $(".selector").igDataChart("option", "axes",
          [{
              name: "xAxis",
              type: "numericX",
              title: "Years",
              titleVerticalAlignment: "center"
          }]
      );

• type

  Type:

  enumeration

  Default:

  null

  Type of the axis.

  Members

  • numericX
  • Type:string
  • Specify the axis as numeric X axis. Useful for displaying scatter, category and financial price series.
  • numericY
  • Type:string
  • Specify the axis as numeric Y axis.Useful for displaying scatter, category and financial price series.
  • categoryX
  • Type:string
  • Specify the axis as category X axis. Useful for displaying scatter, category and financial price series.
  • categoryDateTimeX
  • Type:string
  • Specify the axis as category datetime X axis. Useful for displaying category and financial price series with date based data.
  • categoryY
  • Type:string
  • Specify the axis as category Y axis. Useful for displaying scatter, category and financial price series.
  • categoryAngle
  • Type:string
  • Specify the axis as category angle axis. Useful for displaying polar and radial categories.
  • numericAngle
  • Type:string
  • Specify the axis as numeric angle axis. Useful for displaying polar and radial series.
  • numericRadius
  • Type:string
  • Specify the axis as numeric radius axis. Useful for displaying polar and radial series.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }]
      });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].type;

  //    Set
  $(".selector").igDataChart("option", "axes", blue
          [{
              name: "xAxis",
              type: "numericX"
          }]
      );


• useClusteringMode

  Type:

  bool

  Default:

  false

  Gets or sets whether the cateogory axis should use clustering display mode even if no series are present that would force clustering mode.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
      axes: [{
          name: "xAxis",
          type: "categoryX",
          useClusteringMode: true
      }]
  });

  //    Get
  var axes = $(".selector").igDataChart("option", "axes");
  axes[0].useClusteringMode;

  //    Set
  $(".selector").igDataChart("option", "axes",
      [{
          name: "xAxis",
          type: "categoryX",
          useClusteringMode: true
      }]
  );


• useEnhancedIntervalManagement

  Type:

  bool

  Default:

  false

  Gets or sets whether to use more advanced heuristics when determining the initial number of labels to render, before resolving collisions, etc.

Sets or gets the bottom margin to use around the chart content in the canvas.


        //Initialize
        $(".selector").igDataChart({
            bottomMargin : 20
        });

        //Get
        var margin = $(".selector").igDataChart("option", "bottomMargin");

        //Set
        $(".selector").igDataChart("option", "bottomMargin", 20);

Gets or sets the Brushes property.
The brushes property defines the palette from which automatically assigned series brushes are selected.
The value provided should be an array of css color strings. Optionally the first element can be a string reading "RGB" or "HSV" to specify the interpolation mode of the collection.

		//	Initialization
		$(".selector").igDataChart({
                brushes: [ "#ff0000", "#ffff00", "#00ffff" ]
            });

		//	Get
		var brushes = $(".selector").igDataChart("option", "brushes");

		//	Set
		$(".selector").igDataChart("option", "brushes", [ "#ff0000", "#ffff00", "#00ffff" ]);


Gets or sets the template to use for circle markers on the chart.
Defines the marker template used for
series with a marker type of circle.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    circleMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


Gets or sets which type of hit testing the series should use.

//	Initialization
$(".selector").igDataChart({
    contentHitTestMode: "auto"
});

//	Get
var mode= $(".selector").igDataChart("option", "contentHitTestMode");

//	Set
$(".selector").igDataChart("option", "contentHitTestMode", "auto");


Gets or sets the cross hair point (in world coordinates)
Either or both of the crosshair point's X and Y may be set to double.NaN, in which
case the relevant crosshair line is hidden.

//	Initialization
$(".selector").igDataChart({
    crosshairPoint: { x: 0.5, y: 0.5 }
});

//	Get
var crosshairPoint = $(".selector").igDataChart("option", "crosshairPoint");

//	Set
$(".selector").igDataChart("option", "crosshairPoint", { x: 0.5, y: 0.5 });


• x

  Type:

  number

  Default:

  ""

  The x coordinate.

  Code Sample

  //  Initialization
  $(".selector").igDataChart({
      crosshairPoint: { x: 0.5, y: 0.5 }
  });

  //  Get
  var crosshairPoint = $(".selector").igDataChart("option", "crosshairPoint");
  var x =  crosshairPoint.x;

  //	Set
  $(".selector").igDataChart("option", "crosshairPoint", { x: 0.5, y: 0.5 });


• y

  Type:

  number

  Default:

  ""

  The y coordinate.

  Code Sample

  //  Initialization
  $(".selector").igDataChart({
      crosshairPoint: { x: 0.5, y: 0.5 }
  });

  //  Get
  var crosshairPoint = $(".selector").igDataChart("option", "crosshairPoint");
  var y =  crosshairPoint.y;

  //	Set
  $(".selector").igDataChart("option", "crosshairPoint", { x: 0.5, y: 0.5 });


Gets or sets the current Chart's crosshair visibility override. Note: setting this property does not affect the mobile browser version of the chart.

		//	Initialization
		$(".selector").igDataChart({
                crosshairVisibility: "collapsed"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "crosshairVisibility");

		//	Set
		$(".selector").igDataChart("option", "crosshairVisibility", "collapsed");


Can be any valid data source accepted by $.ig.DataSource, or an instance of an $.ig.DataSource itself.

		//	Initialization
		var data1 = [{"ID": 1, "Cost": 12.5}, {"ID": 2, "Cost": 18.56}, {"ID": 3, "Cost": 22.18}];
		$(".selector").igDataChart({
                dataSource: data1
            });

		//	Get
		var dataSource = $(".selector").igDataChart("option", "dataSource");

		//	Set
		var data1 = [{"ID": 1, "Cost": 12.5}, {"ID": 2, "Cost": 18.56}, {"ID": 3, "Cost": 22.18}];
		$(".selector").igDataChart("option", "dataSource", data1);


Explicitly set data source type (such as "json"). Please refer to the documentation of $.ig.DataSource and its type property.

		//	Initialization
		$(".selector").igDataChart({
                dataSourceType: "array"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "dataSourceType");

		//	Set
		$(".selector").igDataChart("option", "dataSourceType", "array");


Specifies a remote URL accepted by $.ig.DataSource in order to request data from it.

		//	Initialization
		$(".selector").igDataChart({
                dataSourceUrl: "http://www.example.com"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "dataSourceUrl");

		//	Set
		$(".selector").igDataChart("option", "dataSourceUrl", "http://www.example.com");


Gets or sets the DefaultInteraction property. The default interaction state defines the chart's response to mouse events.

		//	Initialization
		$(".selector").igDataChart({
                defaultInteraction: "dragZoom"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "defaultInteraction");

		//	Set
		$(".selector").igDataChart("option", "defaultInteraction", "dragZoom");


Gets or sets the template to use for diamond markers on the chart.
Defines the marker template used for
series with a marker type of diamond.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    diamondMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


Gets or sets the current Chart's DragModifier property.

		//	Initialization
		$(".selector").igDataChart({
                dragModifier: "control"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "dragModifier");

		//	Set
		$(".selector").igDataChart("option", "dragModifier", "control");


Gets or sets the GridMode property.

		//	Initialization
		$(".selector").igDataChart({
                gridMode: "beforeSeries"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "gridMode");

		//	Set
		$(".selector").igDataChart("option", "gridMode", "beforeSeries");


The height of the chart. It can be set as a number in pixels, string (px) or percentage (%).

//	Initialization
$(".selector").igDataChart({
    height: 250
});

//	Get
var opValue = $(".selector").igDataChart("option", "height");

//	Set
$(".selector").igDataChart("option", "height", 250);


Gets or sets the template to use for hexagon markers on the chart.
Defines the marker template used for
series with a marker type of hexagon.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    hexagonMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


Gets or sets the template to use for hexagram markers on the chart.
Defines the marker template used for
series with a marker type of hexagram.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    hexagramMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


The length, in milliseconds of the highlighting transition.


       //Initialization
<script type="text/javascript">
    $(function () {
        $("#chart").igDataChart({
                width: "100%",
                height: "400px",
                legend: { element: "lineLegend" },
                title: "Population per Country",
                subtitle: "A comparision of population in 1995 and 2005",
                dataSource: data,
                axes: [
                    {
                        name: "NameAxis",
                        type: "categoryX",
                        label: "CountryName"
                    },
                    {
                        name: "PopulationAxis",
                        type: "numericY"
                    }
                ],
                series: [
                    {
                        name: "2005Population",
                        type: "line",
                        title: "2005",
                        xAxis: "NameAxis",
                        yAxis: "PopulationAxis",
                        valueMemberPath: "Pop2005",
                        isHighlightingEnabled: true,
                        highlightingTransitionDuration: 500
                    }
                ]
            });
    });
</script>

//Get
var series = $(".selector").igDataChart("option", "series");
series[0].highlightingTransitionDuration;

//Set
$(".selector").igDataChart("option", "series",
        [{
            name: "2005Population",
            type: "line",
            title: "2005",
            xAxis: "NameAxis",
            yAxis: "PopulationAxis",
            valueMemberPath: "Pop2005",
            highlightingTransitionDuration: 500
        }]
    );


Gets or sets the current Chart's horizontal zoomability.

		//	Initialization
		$(".selector").igDataChart({
                horizontalZoomable: true
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "horizontalZoomable");

		//	Set
		$(".selector").igDataChart("option", "horizontalZoomable", true);


Gets or sets whether the series viewer can allow the page to pan if a control pan is not possible in the requested direction.

		//	Initialization
		$(".selector").igDataChart({
                isPagePanningAllowed: true
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "isPagePanningAllowed");

		//	Set
		$(".selector").igDataChart("option", "isPagePanningAllowed", true);


Gets or sets whether to use a square aspect ratio for the chart. This is locked to true for polar and radial charts.

		//	Initialization
		$(".selector").igDataChart({
                isSquare: true
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "isSquare");

		//	Set
		$(".selector").igDataChart("option", "isSquare", true);


Set to true in order to disable any interactions with the plot surface.

//	Initialization
$(".selector").igDataChart({
    isSurfaceInteractionDisabled: true
});

//	Get
var opValue = $(".selector").igDataChart("option", "isSurfaceInteractionDisabled");

//	Set
$(".selector").igDataChart("option", "isSurfaceInteractionDisabled", true);

Sets or gets the left margin to use around the chart content in the canvas.


        //Initialize
        $(".selector").igDataChart({
            leftMargin : 20
        });

        //Get
        var margin = $(".selector").igDataChart("option", "leftMargin");

        //Set
        $(".selector").igDataChart("option", "leftMargin", 20);

Can be any valid options accepted by $.ig.ChartLegend, or an instance of an $.ig.ChartLegend itself.

// Initialize
$(".selector").igDataChart({
    legend: {
        element: 'legend',
        type: 'legend'
    }
});

// Get
var legend = $(".selector").igDataChart("option", "legend");

// Set
$(".selector").igDataChart("option", "legend", {
    element: 'legend',
    type: 'legend'
});


• element

  Type:

  string

  Default:

  null

  The name of the element to turn into a legend.

  Code Sample

  // Initialize
  $(".selector").igDataChart({
  	  legend: {
          element: "legend",
          type: "legend"
      }
  });

  // Get
  var legend = $(".selector").igDataChart("option", "legend");
  legend.element;


• height

  Type:

  enumeration

  Default:

  null

  The height of the legend. null will stretch vertically to fit data, no other height are defined.

  Members

  • null
  • Type:object

  • string
  • The widget height can be set in pixels (px) and percentage (%).
  • number
  • The widget height can be set as a number.

  Code Sample


  // Initialize
  $(".selector").igDataChart({
  	  legend: {
          element: "legend",
          type: "legend",
          height: "100px"
      }
  });

  // Get
  var legend = $(".selector").igDataChart("option", "legend");
  legend.height;


• type

  Type:

  enumeration

  Default:

  legend

  Type of the legend.

  Members

  • item
  • Type:string
  • Specify the legend as item legend. It displays a legend item for each pie in the igPieChart control.
  • legend
  • Type:string
  • Specify the legend as legend. It is supported by all types of series in the igDataChart control.

  Code Sample


  // Initialize
  $(".selector").igDataChart({
  	  legend: {
          element: "legend",
          type: "legend"
      }
  });

  // Get
  var legend = $(".selector").igDataChart("option", "legend");
  legend.type;


• width

  Type:

  enumeration

  Default:

  null

  The width of the legend.

  Members

  • null
  • Type:object
  • will stretch to fit data, if no other widths are defined.

  • string
  • The widget width can be set in pixels (px) and percentage (%).
  • number
  • The widget width can be set as a number.

  Code Sample


  // Initialize
  $(".selector").igDataChart({
  	  legend: {
          element: "legend",
          type: "legend",
          width: "100px"
      }
  });

  //Get
  var legend = $(".selector").igDataChart("option", "legend");
  legend.width;


Gets or sets the MarkerBrushes property.
The marker brushes property defines the palette from which automatically assigned marker brushes are selected.
The value provided should be an array of css color strings. Optionally the first element can be a string reading "RGB" or "HSV" to specify the interpolation mode of the collection.

		//	Initialization
		$(".selector").igDataChart({
                markerBrushes: [ "#ff0000", "#ffff00", "#00ffff" ]
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "markerBrushes");

		//	Set
		$(".selector").igDataChart("option", "markerBrushes", [ "#ff0000", "#ffff00", "#00ffff" ]);


Gets or sets the MarkerOutlines property.
The marker outlines property defines the palette from which automatically assigned marker outlines are selected.
The value provided should be an array of css color strings. Optionally the first element can be a string reading "RGB" or "HSV" to specify the interpolation mode of the collection.

		//	Initialization
		$(".selector").igDataChart({
                markerOutlines: [ "#ff0000", "#ffff00", "#00ffff" ]
            });

		//	Get
		var markerOutlines = $(".selector").igDataChart("option", "markerOutlines");

		//	Set
		$(".selector").igDataChart("option", "markerOutlines", [ "#ff0000", "#ffff00", "#00ffff" ]);


Gets or sets the Outlines property.
The outlines property defines the palette from which automatically assigned series outlines are selected.
The value provided should be an array of css color strings. Optionally the first element can be a string reading "RGB" or "HSV" to specify the interpolation mode of the collection.

		//	Initialization
		$(".selector").igDataChart({
                outlines: [ "#ff0000", "#ffff00", "#00ffff" ]
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "outlines");

		//	Set
		$(".selector").igDataChart("option", "outlines", [ "#ff0000", "#ffff00", "#00ffff" ]);


The visibility of the OverviewPlusDetailPane.

		//	Initialization
		$(".selector").igDataChart({
                overviewPlusDetailPaneVisibility: "visible"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "overviewPlusDetailPaneVisibility");

		//	Set
		$(".selector").igDataChart("option", "overviewPlusDetailPaneVisibility", "visible");


Gets or sets the current Chart's PanModifier property.

		//	Initialization
		$(".selector").igDataChart({
                panModifier: "control"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "panModifier");

		//	Set
		$(".selector").igDataChart("option", "panModifier", "control");


Gets or sets the template to use for pentagon markers on the chart.
Defines the marker template used for
series with a marker type of pentagon.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    pentagonMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


Gets or sets the template to use for pentragram markers on the chart.
Defines the marker template used for
series with a marker type of pentagram.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    pentagramMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


Gets or sets the scaling value used by the main canvas rendering context to apply a scale transform to it.


//Initialize
$(".selector").igDataChart({
    pixelScalingRatio: 2
});

//Get
var pixelScalingRatio = $(".selector").igDataChart("option", "pixelScalingRatio");
//Set
$(".selector").igDataChart("option", "pixelScalingRatio", 2);


Gets or sets the brush used as the background for the current Chart object's plot area.


//Initialize
$(".selector").igDataChart({
    plotAreaBackground: "grey"
});

//Get
var plotAreaBackground = $(".selector").igDataChart("option", "plotAreaBackground");
//Set
var plotAreaBackground = $(".selector").igDataChart("option", "plotAreaBackground", "grey");


Sets whether the series viewer should prefer selecting higher resolution tiles over lower resolution tiles when performing tile zooming. Setting this to true will lower performance but increase quality.


//Initialize
$(".selector").igDataChart({
    preferHigherResolutionTiles: true
});

//Get
var preferHigherRes= $(".selector").igDataChart("option", "preferHigherResolutionTiles");

//Set
$(".selector").igDataChart("option", "preferHigherResolutionTiles", true);


Gets or sets the preview rectangle.
The preview rectangle may be set to Rect.Empty, in which case the visible preview
strokePath is hidden.
The provided object should have numeric properties called left, top, width and height.

// Initialization
$(".selector").igDataChart({
    previewRect: {
        left: 0.3,
        top: 0.3,
        width: 0.5,
        height: 0.5
    }
});

// Get
var previewRect = $(".selector").igDataChart("option", "previewRect");

// Set
$(".selector").igDataChart("option", "previewRect", {
    left: 0.3,
    top: 0.3,
    width: 0.5,
    height: 0.5
});


Gets or sets the template to use for pyramid markers on the chart.
Defines the marker template used for
series with a marker type of pyramid.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    pyramidMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


See $.ig.DataSource. Specifies the name of the property in which data records are held if the response is wrapped.


// Initialize
$(".selector").igDataChart({
    responseDataKey: "Records"
});

// Get
var responseDataKey = $(".selector").igDataChart("option", "responseDataKey");
// Set
var responseDataKey = $(".selector").igDataChart("option", "responseDataKey", "Records");


Sets or gets the right margin to use around the chart content in the canvas.


        //Initialize
        $(".selector").igDataChart({
            rightMargin : 20
        });

        //Get
        var margin = $(".selector").igDataChart("option", "rightMargin");

        //Set
        $(".selector").igDataChart("option", "rightMargin", 20);

An array of series objects.

// Initialization
var data = [{ "Label": "1/1/2012", "Item1": 980, "Item2": 1000 }, { "Label": "1/2/2012", "Item1": 1200, "Item2": 1500 }];

$(".selector").igDataChart({
    axes: [{
        name: "xAxis",
        type: "categoryX",
        dataSource: data,
        label: "Label"
    }, {
        name: "yAxis",
        type: "numericY"
    }],
    series: [{
        name: "series1",
        dataSource: data,
        title: "Price Series 1",
        type: "column",
        xAxis: "xAxis",
        yAxis: "yAxis",
        valueMemberPath: "Item1"
    }]
});

// Get
var series = $(".selector").igDataChart("option", "series");
series[0];

// Set
$(".selector").igDataChart("series",
    [{
        name: "series2",
        dataSource: data,
        title: "Price Series 2",
        type: "column",
        xAxis: "xAxis",
        yAxis: "yAxis",
        valueMemberPath: "Item1"
    }]
);


• angleAxis

  Type:

  string

  Default:

  null

  Gets the effective angle axis for the current series object.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
      axes: [{
          name: "angleAxis",
          type: "categoryAngle",
          label: "Label"
      }, {
          name: "radiusAxis",
          type: "numericRadius"
      }],
      series: [{
          name: "series1",
          dataSource: data,
          title: "Budget",
          type: "radialLine",
          angleAxis: "angleAxis",
          valueAxis: "radiusAxis",
          valueMemberPath: "Budget",
      }]
  });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].angleAxis;

  // Set
  var series = $(".selector").igDataChart("option",
      [{
          name: "series1",
          dataSource: data,
          title: "Budget",
          type: "radialLine",
          angleAxis: "angleAxis",
          valueAxis: "radiusAxis",
          valueMemberPath: "Budget",
      }]
  );


• angleMemberPath

  Type:

  number

  Default:

  null

  Gets or sets the x-radius of the ellipse that is used to round the corners of the column.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "angleAxis",
              type: "numericAngle"
          },
          {
              name: "radiusAxis",
              type: "numericRadius"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "polarScatter",
              angleAxis: "angleAxis",
              radiusAxis: "radiusAxis",
              angleMemberPath: "Index",
              radiusMemberPath: "Value1"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].angleMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              title: "Sales",
              type: "polarScatter",
              angleAxis: "angleAxis",
              radiusAxis: "radiusAxis",
              angleMemberPath: "Index",
              radiusMemberPath: "Value1"
          }]
      );


• areaFillOpacity

  Type:

  number

  Default:

  1.0

  Gets or sets the opacity modifier to apply to the area fill shape of the series, if applicable.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "area",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              areaFillOpacity: 0.8
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].areaFillOpacity;

  // Set
  $(".selector").igDataChart("series",
          [{
              name: "series1",
              areaFillOpacity: 0.8
          }]
      );


• bandHighlightWidth

  Type:

  number

  Default:

  10.0

  Gets or sets the width to use for the highlight region if highlighting items in a grid aligned series (line, spline, etc), with a banded shape.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              bandHighlightWidth: 5.0
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].bandHighlightWidth;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              bandHighlightWidth: 5.0
          }]
      );


• brush

  Type:

  string

  Default:

  null

  Gets or sets the brush to use for the series.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              brush: "blue"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].brush;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              brush: "blue"
          }]
      );


• clipSeriesToBounds

  Type:

  bool

  Default:

  null

  Gets or sets whether to clip the series to the bounds.
  Setting this to true can effect performance.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              clipSeriesToBounds: true
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].clipSeriesToBounds;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              clipSeriesToBounds: true
          }]
      );


• closeMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the close mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].closeMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      );


• coercionMethods

  Type:

  object

  Default:

  null

  Gets or gets the coercion methods to use when loading data from data sources.
  Should be specified before setting any member paths, if being used. Setting it later
  will not cause data to be reimported into the chart.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryDateTimeX",
              dataSource: data,
              label: "Date"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "line",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value!roundTo50",
              coercionMethods: {
                  roundTo100: function (val) {
                      var newVal = Math.round(val / 100) <dependency>100;
                      return newVal;
                  }
              }
          }]
      });


• consolidatedColumnVerticalPosition

  Type:

  enumeration

  Default:

  median

  Gets or sets value that is used to determine positioning logic for data items which have been consolidated into a single visual element.

  Members

  • maximum
  • Type:string
  • Consolidated items will be positioned using their maximum value.
  • minimum
  • Type:string
  • Consolidated items will be positioned using their minimum value.
  • median
  • Type:string
  • Consolidated items will be positioned using their median value.
  • relativeMinimum
  • Type:string
  • Consolidated items will be positioned using the value nearest to the reference value of the corresponding axis.
  • relativeMaximum
  • Type:string
  • Consolidated items will be positioned using the value farthest from the reference value of the corresponding axis.

  Code Sample

            $(".selector").igDataChart({
              axes: [{
                  name: "xAxis",
                  type: "categoryX",
              }, {
                  name: "yAxis",
                  type: "numericY"
              }],
              series: [{
                  name: "series1",
                  type: "column",
                  xAxis: "xAxis",
                  yAxis: "yAxis",
                  consolidatedColumnVerticalPosition: "maximum"
              }]
          });


• cursorPosition

  Type:

  object

  Default:

  null

  Sets the position a cursor position to use instead of the current mouse cursor position for displaying the annotations in this layer.
  Should be an object with an x and a y property in world coordinates (ranging from 0 to 1).

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  name: "crosshairLayer",
                  title: "crosshair",
                  type: "crosshairLayer",
                  cursorPosition: {x:0.5 , y:0.5}
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].cursorPosition;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "crosshairLayer",
              title: "crosshair",
              type: "crosshairLayer",
              cursorPosition: {x:0.5 , y:0.5}
          }]
      );


• dataSource

  Type:

  object

  Default:

  null

  Can be any valid data source accepted by $.ig.DataSource, or an instance of an $.ig.DataSource itself.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].dataSource;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      );


• dataSourceType

  Type:

  string

  Default:

  null

  Explicitly set data source type (such as "json"). Please refer to the documentation of $.ig.DataSource and its type property.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              dataSourceType: "json",
              title: "Price",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1"
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].dataSourceType;

  // Set
  $(".selector").igDataChart("option", "series",
      [{
          name: "series1",
          dataSource: data,
          dataSourceType: "json",
          title: "Price",
          type: "column",
          xAxis: "xAxis",
          yAxis: "yAxis",
          valueMemberPath: "Item1"
      }]
  );


• dataSourceUrl

  Type:

  string

  Default:

  null

  Specifies a remote URL accepted by $.ig.DataSource in order to request data from it.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSourceUrl: "http://www.example.com/price-data",
              dataSourceType: "json",
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].dataSource;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSourceUrl: "http://www.example.com/price-data",
              dataSourceType: "json",
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      );


• discreteLegendItemTemplate

  Type:

  object

  Default:

  null

  Gets or sets the DiscreteLegendItemTemplate property.
  The legend item control content is created according to the DiscreteLegendItemTemplate on-demand by
  the series object itself.
  The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              discreteLegendItemTemplate: {
                  measure: function(measureInfo) {
                      measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
                      measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
                      measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
                      measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
                      measureInfo.data;       // if present, represents the contextual data for this template]
                  },
                  render: function (renderInfo) {
                      renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
                      renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
                      renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
                      renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
                      renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
                      renderInfo.data;               //    if present, specifies the data that is in context for this content
                      renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
                  }
              }
          }]
      });


• displayType

  Type:

  enumeration

  Default:

  candlestick

  Gets or sets the display for the current FinancialIndicator object.

  Members

  • candlestick
  • Type:string
  • Displays prices as a Japanese Candlestick.
  • OHLC
  • Type:string
  • Displays prices as an OHLC bar.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
      axes: [{
          name: "xAxis",
          type: "categoryX",
          dataSource: data,
          label: "Label"
      }, {
          name: "yAxis",
          type: "numericY"
      }],
      series: [{
          name: "series1",
          dataSource: data,
          title: "Price",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          type: "averageTrueRangeIndicator",
          displayType: "area"
      }]
  });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].displayType;

  // Set
  $(".selector").igDataChart("option", "series",
      [{
          name: "series1",
          dataSource: data,
          title: "Price",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          type: "averageTrueRangeIndicator",
          displayType: "area"
      }]
  );


• expectFunctions

  Type:

  bool

  Default:

  false

  Gets or sets whether the series should expect that its data source members need to be called as functions to get their values.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "area",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              expectFunctions: false
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].expectFunctions;

  // Set
  $(".selector").igDataChart("series",
          [{
              name: "series1",
              expectFunctions: false
          }]
      );


• fillMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the fill mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "bubble",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              radiusMemberPath: "Value2",
              fillMemberPath: "Value3",
              labelMemberPath: "Value2"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].fillMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "bubble",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              radiusMemberPath: "Value2",
              fillMemberPath: "Value3",
              labelMemberPath: "Value2"
          }]
      );


• fillScale

  Type:

  object

  Default:

  null

  Gets or sets the brush scale for the marker brush.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "bubble",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              radiusMemberPath: "Value2",
              fillMemberPath: "Value3",
              labelMemberPath: "Value2",
              fillScale: {
                        type: "value",
                        brushes: ["red", "blue"],
                        minimumValue: 0,
                        maximumValue: 20
                    }
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].fillScale;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "bubble",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              radiusMemberPath: "Value2",
              fillMemberPath: "Value3",
              labelMemberPath: "Value2",
              fillScale: {
                        type: "value",
                        brushes: ["red", "blue"],
                        minimumValue: 0,
                        maximumValue: 20
                    }
          }]
      );


• heatMaximum

  Type:

  number

  Default:

  50

  Gets or sets the value that maps to the maximum heat color.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
      series: [{
          name: "series1",
  	      type: "highDensityScatter",
  	      xAxis: "xAxis",
  	      yAxis: "yAxis",
  	      xMemberPath: "Index",
  	      yMemberPath: "Value1",
          heatMaximum: 100
      }]
  });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].heatMaximum;

  //Set
  $(".selector").igDataChart("option", "series", [{
      name: "series1",
  	  type: "highDensityScatter",
  	  xAxis: "xAxis",
  	  yAxis: "yAxis",
  	  xMemberPath: "Index",
  	  yMemberPath: "Value1"
      heatMaximum: 100
  }]);


• heatMaximumColor

  Type:

  object

  Default:

  red

  Gets or sets the maximum heat color for the density scale.

  Code Sample


            // Initialization
  $(".selector").igDataChart({
      series: [{
          name: "series1",
  	      type: "highDensityScatter",
  	      xAxis: "xAxis",
  	      yAxis: "yAxis",
  	      xMemberPath: "Index",
  	      yMemberPath: "Value1",
          heatMaximumColor: "red"
      }]
  });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].heatMaximumColor;

  // Set
  $(".selector").igDataChart("option", "series", [{
      name: "series1",
  	  type: "highDensityScatter",
  	  xAxis: "xAxis",
  	  yAxis: "yAxis",
  	  xMemberPath: "Index",
  	  yMemberPath: "Value1",
      heatMaximumColor: "red"
  }]);

• heatMinimum

  Type:

  number

  Default:

  0

  Gets or sets the density value that maps to the minimum heat color.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
      series: [{
          name: "series1",
  	      type: "highDensityScatter",
  	      xAxis: "xAxis",
  	      yAxis: "yAxis",
  	      xMemberPath: "Index",
  	      yMemberPath: "Value1",
          heatMinimum: 5
      }]
  });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].heatMinimum;

  // Set
  $(".selector").igDataChart("option", "series", [{
      name: "series1",
  	  type: "highDensityScatter",
  	  xAxis: "xAxis",
  	  yAxis: "yAxis",
  	  xMemberPath: "Index",
  	  yMemberPath: "Value1",
      heatMinimum: 5
  }]);


• heatMinimumColor

  Type:

  object

  Default:

  black

  Gets or sets the minimum heat color for the density scale.

  Code Sample


            // Initialization
  $(".selector").igDataChart({
      series: [{
          name: "series1",
  	      type: "highDensityScatter",
  	      xAxis: "xAxis",
  	      yAxis: "yAxis",
  	      xMemberPath: "Index",
  	      yMemberPath: "Value1",
          heatMinimumColor: "black"
      }]
  });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].heatMinimumColor;

  // Set
  $(".selector").igDataChart("option", "series", [{
      name: "series1",
  	  type: "highDensityScatter",
  	  xAxis: "xAxis",
  	  yAxis: "yAxis",
  	  xMemberPath: "Index",
  	  yMemberPath: "Value1",
      heatMinimumColor: "black"
  }]);


• highlightType

  Type:

  enumeration

  Default:

  auto

  Gets or sets which type of highlight shape to use when highlighting items.

  Members

  • auto
  • Type:string
  • use an automatic highlight type for this series.
  • marker
  • Type:string
  • use a marker highlight type for this series.
  • shape
  • Type:string
  • use a shape highlight type for this series.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
                  width: "100%",
                  height: "400px",
                  legend: { element: "lineLegend" },
                  title: "Population per Country",
                  subtitle: "A comparision of population in 1995 and 2005",
                  dataSource: data,
                  axes: [
                      {
                          name: "NameAxis",
                          type: "categoryX",
                          label: "CountryName"
                      },
                      {
                          name: "PopulationAxis",
                          type: "numericY"
                      }
                  ],
                  series: [
                      {
                          name: "2005Population",
                          type: "line",
                          title: "2005",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop2005",
                          isHighlightingEnabled: true,
                          highlightType: "marker"
                      }
                  ]
              });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].highlightType;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "2005Population",
              type: "line",
              title: "2005",
              xAxis: "NameAxis",
              yAxis: "PopulationAxis",
              valueMemberPath: "Pop2005",
              isHighlightingEnabled: true,
              highlightType: "marker"
          }]
      );


• highMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the value mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].highMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      );


• hitTestMode

  Type:

  enumeration

  Default:

  auto

  Gets or sets which type of hit testing the series should use.

  Members

  • auto
  • Type:string
  • automatically decide the appropriate hit test mode for the series.
  • computational
  • Type:string
  • use a computational based approach to determine whether the series has been hit. This uses loose bounding boxes, in some cases, and can range in time complexity between O(1) and O(log n) to find a hit. This decreases frame render time compared to color encoded.
  • colorEncoded
  • Type:string
  • use a color encoded off screen buffer for hit testing. This can have extremely rare false positives where the wrong series is hit (this is due to our inability to disable anti-aliasing in our color buffer), but should always be O(1) time for determining a hit series. This increases frame render time, however. Consider using this if hit testing time is degrading performance.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "area",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              hitTestMode: auto
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].hitTestMode;

  // Set
  $(".selector").igDataChart("series",
          [{
              name: "series1",
              hitTestMode: false
          }]
      );


• horizontalLineVisibility

  Type:

  enumeration

  Default:

  visible

  Gets or sets whether the horizontal crosshair portion of the layer should be visible.

  Members

  • visible
  • Type:string
  • the horizontal crosshair portion of the layer should be visible.
  • collapsed
  • Type:string
  • the horizontal crosshair portion of the layer should not be visible.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "column",
                  name: "2005Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop2005"
              },            {
                  type: "line",
                  name: "1995Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop1995"
              },            {
                  type: "crosshairLayer",
                  name: "crosshairLayer",
                  title: "crosshair",
                  useInterpolation: false,
                  transitionDuration: 500,
                  targetSeries: "2005Population",
                  horizontalLineVisibility: "visible"
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[2].horizontalLineVisibilty;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "crosshairLayer",
              title: "crosshair",
              type: "crosshairLayer",
              horizontalLineVisiblity: "visible"
          }]
      );


• ignoreFirst

  Type:

  number

  Default:

  0

  Gets or sets the number of values to hide at the beginning of the indicator.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              ignoreFirst: 2
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].ignoreFirst;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              ignoreFirst: 2
          }]
      );


• isCustomCategoryMarkerStyleAllowed

  Type:

  bool

  Default:

  false

  Gets or sets whether a custom category marker style is allowed. Setting this to true will case the assigningCategoryMarkerStyle event to get fired, if provided.

  Code Sample


  //Initialization
  <script type="text/javascript">
        $(function () {
              $("#chart").igDataChart({
                dataSource: data,
                axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
                }, {
                type: "numericY",
                name: "PopulationAxis",
              }],
              series: [{
                  type: "categoryHighlightLayer",
                  name: "categoryHighlightLayer",
                  title: "categoryHighlight",
                  useInterpolation: false,
                  transitionDuration: 500,
                  targetSeries: "2005Population",
                  isCustomCategoryMarkerStyleAllowed: "true"
                }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].isCustomCategoryMarkerStyleAllowed;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              type: "categoryHighlightLayer",
              name: "categoryHighlightLayer",
              title: "categoryHighlight",
              isCustomCategoryMarkerStyleAllowed: "true"
          }]
      );


• isCustomCategoryStyleAllowed

  Type:

  bool

  Default:

  false

  Gets or sets whether a custom category style is allowed. Setting this to true will case the assigningCategoryStyle event to get fired, if provided.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "categoryHighlightLayer",
                  name: "categoryHighlightLayer",
                  title: "categoryHighlight",
                  useInterpolation: false,
                  transitionDuration: 500,
                  targetSeries: "2005Population",
                  isCustomCategoryStyleAllowed: "true"
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].isCustomCategoryStyleAllowed;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "crosshairLayer",
              title: "crosshair",
              type: "crosshairLayer",
              isCustomCategoryStyleAllowed: "true"
          }]
      );

• isDefaultCrosshairDisabled

  Type:

  bool

  Default:

  true

  Sets if the presence of this layer should disable the default crosshair behavior of the chart, if present.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "categoryHighlightLayer",
                  name: "categoryHighlightLayer",
                  title: "categoryHighlight",
                  isDefaultCrosshairDisabled: "true"
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].isDefaultCrosshairDisabled;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
             type: "categoryHighlightLayer",
             name: "categoryHighlightLayer",
             title: "categoryHighlight",
             isDefaultCrosshairDisabled: "true"
          }]
      );


• isDropShadowEnabled

  Type:

  bool

  Default:

  false

  Gets or sets whether drop shadow should be enabled for this series.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              isDropShadowEnabled: true
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].isDropShadowEnabled;

  // Set
  $(".selector").igDataChart("series",
          [{
              name: "series1",
              isDropShadowEnabled: true
          }]
      );


• isHighlightingEnabled

  Type:

  bool

  Default:

  false

  Gets or sets whether highlighting should be enabled for the series, if supported.

  Code Sample


          //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
                  dataSource: data,
                  axes: [
                      {
                          name: "NameAxis",
                          type: "categoryX",
                          label: "CountryName"
                      },
                      {
                          name: "PopulationAxis",
                          type: "numericY",
                          minimumValue: 0
                      }
                  ],
                  series: [
                      {
                          name: "2005Population",
                          type: "line",
                          title: "2005",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop2005",
                          isHighlightingEnabled: true
                      },
                      {
                          name: "1995Population",
                          type: "line",
                          title: "1995",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop1995",
                          isHighlightingEnabled: true
                      }
                  ]
              });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].isHighlightingEnabled;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "2005Population",
              type: "line",
              title: "2005",
              xAxis: "NameAxis",
              yAxis: "PopulationAxis",
              valueMemberPath: "Pop2005",
              isHighlightingEnabled: true
          }]
      );



• isTransitionInEnabled

  Type:

  bool

  Default:

  false

  Gets or sets if the series should play a transition in animation when the data source is assigned. Note: Transitions are not currently supported for stacked series.

  Code Sample



          //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
                  dataSource: data,
                  axes: [
                      {
                          name: "NameAxis",
                          type: "categoryX",
                          label: "CountryName"
                      },
                      {
                          name: "PopulationAxis",
                          type: "numericY",
                       }
                  ],
                  series: [
                      {
                          name: "2005Population",
                          type: "line",
                          title: "2005",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop2005",
                          isTransitionInEnabled: true
                      },
                      {
                          name: "1995Population",
                          type: "line",
                          title: "1995",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop1995",
                          isTransitionInEnabled: true
                      }
                  ]
              });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].isTransitionInEnabled;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "2005Population",
              type: "line",
              title: "2005",
              xAxis: "NameAxis",
              yAxis: "PopulationAxis",
              valueMemberPath: "Pop2005",
              isTransitionInEnabled: true
          }]
      );


• labelMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the Label mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "bubble",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              radiusMemberPath: "Value2",
              fillMemberPath: "Value3",
              labelMemberPath: "Value2"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].labelMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "bubble",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              radiusMemberPath: "Value2",
              fillMemberPath: "Value3",
              labelMemberPath: "Value2"
          }]
      );


• legend

  Type:

  object

  Default:

  {}

  Can be any valid options accepted by $.ig.ChartLegend, or an instance of an $.ig.ChartLegend itself.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              legend: { element: "legend", type: "legend" }
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].legend;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              legend: { element: "legend", type: "legend" }
          }]
      );


  • element

    Type:

    string

    Default:

    null

    The name of the element to turn into a legend.

    Code Sample

    //Initialization
    $(".selector").igDataChart({
            axes: [{
                name: "xAxis",
                type: "numericX"
            }, {
                name: "yAxis",
                type: "numericY"
            }],
            series: [{
                name: "series1",
                type: "scatter",
                xAxis: "xAxis",
                yAxis: "yAxis",
                xMemberPath: "Index",
                yMemberPath: "Value1",
                legend: { element: "legend", type: "legend" }
            }]
        });

    //Get
    var series = $(".selector").igDataChart("option", "series");
    series[0].legend.element;

    //Set
    $(".selector").igDataChart("option", "series",
            [{
                name: "series1",
                type: "scatter",
                xAxis: "xAxis",
                yAxis: "yAxis",
                xMemberPath: "Index",
                yMemberPath: "Value1",
                legend: { element: "legend", type: "legend" }
            }]
        );


  • height

    Type:

    enumeration

    Default:

    null

    The height of the legend. null will stretch vertically to fit data, no other height are defined.

    Members

    • null
    • Type:object

    • string
    • The widget height can be set in pixels (px) and percentage (%).
    • number
    • The widget height can be set as a number.

    Code Sample

    //Initialization
    $(".selector").igDataChart({
            axes: [{
                name: "xAxis",
                type: "numericX"
            }, {
                name: "yAxis",
                type: "numericY"
            }],
            series: [{
                name: "series1",
                type: "scatter",
                xAxis: "xAxis",
                yAxis: "yAxis",
                xMemberPath: "Index",
                yMemberPath: "Value1",
                legend: { element: "legend", type: "legend", height: "90px" }
            }]
        });

    //Get
    var series = $(".selector").igDataChart("option", "series");
    series[0].legend.height;

    //Set
    $(".selector").igDataChart("option", "series",
            [{
                name: "series1",
                type: "scatter",
                xAxis: "xAxis",
                yAxis: "yAxis",
                xMemberPath: "Index",
                yMemberPath: "Value1",
                legend: { element: "legend", type: "legend", height: "90px" }
            }]
        );


  • type

    Type:

    enumeration

    Default:

    legend

    Type of the legend.

    Members

    • item
    • Type:string
    • Specify the legend as item legend. It displays a legend item for each pie in the igPieChart control.
    • legend
    • Type:string
    • Specify the legend as legend. It is supported by all types of series in the igDataChart control.

    Code Sample

    //Initialization
    $(".selector").igDataChart({
            axes: [{
                name: "xAxis",
                type: "numericX"
            }, {
                name: "yAxis",
                type: "numericY"
            }],
            series: [{
                name: "series1",
                type: "scatter",
                xAxis: "xAxis",
                yAxis: "yAxis",
                xMemberPath: "Index",
                yMemberPath: "Value1",
                legend: { element: "legend", type: "legend" }
            }]
        });

    //Get
    var series = $(".selector").igDataChart("option", "series");
    series[0].legend.type;

    //Set
    $(".selector").igDataChart("option", "series",
            [{
                name: "series1",
                type: "scatter",
                xAxis: "xAxis",
                yAxis: "yAxis",
                xMemberPath: "Index",
                yMemberPath: "Value1",
                legend: { element: "legend", type: "legend" }
            }]
        );


  • width

    Type:

    enumeration

    Default:

    null

    The width of the legend.

    Members

    • null
    • Type:object
    • will stretch to fit data, if no other widths are defined.

    • string
    • The widget width can be set in pixels (px) and percentage (%).
    • number
    • The widget width can be set as a number.

    Code Sample

    //Initialization
    $(".selector").igDataChart({
            axes: [{
                name: "xAxis",
                type: "numericX"
            }, {
                name: "yAxis",
                type: "numericY"
            }],
            series: [{
                name: "series1",
                type: "scatter",
                xAxis: "xAxis",
                yAxis: "yAxis",
                xMemberPath: "Index",
                yMemberPath: "Value1",
                legend: { element: "legend", type: "legend", width: "90px" }
            }]
        });

    //Get
    var series = $(".selector").igDataChart("option", "series");
    series[0].legend.width;

    //Set
    $(".selector").igDataChart("option", "series",
            [{
                name: "series1",
                type: "scatter",
                xAxis: "xAxis",
                yAxis: "yAxis",
                xMemberPath: "Index",
                yMemberPath: "Value1",
                legend: { element: "legend", type: "legend", width: "90px" }
            }]
        );


• legendItemBadgeTemplate

  Type:

  object

  Default:

  null

  Gets or sets the LegendItemBadgeTemplate property.
  The legend item badge is created according to the LegendItemBadgeTemplate on-demand by
  the series object itself.
  The provided object should have properties called render and optionally measure.
  These are functions which will be called that will be called to handle the user specified custom rendering.
  measure will be passed an object that looks like this:
  {
  context: [either a DOM element or a CanvasContext2D depending on the particular template scenario],
  width: [if value is present, specifies the available width, user may set to desired width for content],
  height: [if value is present, specifies the available height, user may set to desired height for content],
  isConstant: [user should set to true if desired with and height will always be the same for this template],
  data: [if present, represents the contextual data for this template]
  }
  render will be passed an object that looks like this:
  {
  context: [either a DOM element or a CanvasContext2D depending on the particular template scenario],
  xPosition: [if present, specifies the x position at which to render the content],
  yPosition: [if present, specifies the y position at which to render the content],
  availableWidth: [if present, specifies the available width in which to render the content],
  availableHeight: [if present, specifies the available height in which to render the content],
  data: [if present, specifies the data that is in context for this content],
  isHitTestRender: [if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used]
  }.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              legend: { element: "legend", type: "legend" },
              legendItemBadgeTemplate: {
                      measure: function(measureInfo) {
                          measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
                          measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
                          measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
                          measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
                          measureInfo.data;       // if present, represents the contextual data for this template]
                      },
                      render: function (renderInfo) {
                          renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
                          renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
                          renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
                          renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
                          renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
                          renderInfo.data;               //    if present, specifies the data that is in context for this content
                          renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
                      }
                  }
          }]
      });


• legendItemTemplate

  Type:

  object

  Default:

  null

  Gets or sets the LegendItemTemplate property.
  The legend item control content is created according to the LegendItemTemplate on-demand by
  the series object itself.
  The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              legend: { element: "legend", type: "legend" },
              legendItemTemplate: {
                      measure: function(measureInfo) {
                          measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
                          measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
                          measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
                          measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
                          measureInfo.data;       // if present, represents the contextual data for this template]
                      },
                      render: function (renderInfo) {
                          renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
                          renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
                          renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
                          renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
                          renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
                          renderInfo.data;               //    if present, specifies the data that is in context for this content
                          renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
                      }
                  }
          }]
      });


• legendItemVisibility

  Type:

  enumeration

  Default:

  visible

  Gets or sets the legend item visibility for the current series object.

  Members

  • visible
  • Type:string
  • The legend item should be visible.
  • collapsed
  • Type:string
  • The legend item should not be visible.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              legend: { element: "legend", type: "legend" },
              legendItemVisibility: "collapsed"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].legendItemVisibility;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              legend: { element: "legend", type: "legend" },
              legendItemVisibility: "collapsed"
          }]
      );


• longPeriod

  Type:

  number

  Default:

  0

  Gets or sets the short moving average period for the current AbsoluteVolumeOscillatorIndicator object.
  The typical, and initial, value for long AVO periods is 30.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "absoluteVolumeOscillatorIndicator",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              longPeriod: 15
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].longPeriod;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "absoluteVolumeOscillatorIndicator",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              longPeriod: 15
          }]
      );


• lowMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the value mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].lowMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      );


• markerBrush

  Type:

  string

  Default:

  null

  Gets or sets the brush that specifies how the current series object's marker interiors are painted.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerBrush: "blue",
              markerType: "automatic"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].markerBrush;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerBrush: "blue",
              markerType: "automatic"
          }]
      );


• markerCollisionAvoidance

  Type:

  enumeration

  Default:

  none

  Gets or sets the MarkerCollisionAvoidance.

  Members

  • none
  • Type:string
  • No collision avoidance is attempted.
  • omit
  • Type:string
  • Markers that collide will be omitted.
  • fade
  • Type:string
  • Markers that collide will be faded in opacity.
  • omitAndShift
  • Type:string
  • Markers that collide may be shifted or omitted.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerCollisionAvoidance: "fade",
              markerType: "automatic"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].markerCollisionAvoidance;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerCollisionAvoidance: "fade",
              markerType: "automatic"
          }]
      );


• markerOutline

  Type:

  string

  Default:

  null

  Gets or sets the brush that specifies how the current series object's marker outlines are painted.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerOutline: "black",
              markerType: "automatic"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].markerOutline;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerOutline: "black",
              markerType: "automatic"
          }]
      );


• markerTemplate

  Type:

  object

  Default:

  null

  Gets or sets the MarkerTemplate for the current series object.
  The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerType: "automatic",
              markerTemplate: {
                      measure: function(measureInfo) {
                          measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
                          measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
                          measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
                          measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
                          measureInfo.data;       // if present, represents the contextual data for this template]
                      },
                      render: function (renderInfo) {
                          renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
                          renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
                          renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
                          renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
                          renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
                          renderInfo.data;               //    if present, specifies the data that is in context for this content
                          renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
                      }
                  }
          }]
      });


• markerType

  Type:

  enumeration

  Default:

  none

  Gets or sets the marker type for the current series object. If the MarkerTemplate property is set, the setting of the MarkerType property will be ignored.

  Members

  • unset
  • Type:string
  • Marker hasn't been set.
  • none
  • Type:string
  • No markerItems.
  • automatic
  • Type:string
  • Automatic marker shape.
  • circle
  • Type:string
  • Circle marker shape.
  • triangle
  • Type:string
  • Flat-top triangle marker shape.
  • pyramid
  • Type:string
  • Flat-base triangle marker shape.
  • square
  • Type:string
  • Square marker shape.
  • diamond
  • Type:string
  • Diamond marker shape.
  • pentagon
  • Type:string
  • Pentagon marker shape.
  • hexagon
  • Type:string
  • Hexagon marker shape.
  • tetragram
  • Type:string
  • Four-pointed star marker shape.
  • pentagram
  • Type:string
  • Five-pointed star marker shape.
  • hexagram
  • Type:string
  • Six-pointed star marker shape.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerType: "automatic"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].markerType;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerType: "automatic"
          }]
      );


• maximumMarkers

  Type:

  number

  Default:

  400

  Gets or sets the maximum number of markerItems displayed by the current series.
  If more than the specified number of markerItems are visible, the series will automatically
  choose a representative set.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerType: "automatic",
              maximumMarkers: 100
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].maximumMarkers;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerType: "automatic",
              maximumMarkers: 100
          }]
      );


• mouseOverEnabled

  Type:

  bool

  Default:

  false

  Gets or sets whether the chart reacts to mouse move events.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerType: "automatic",
              mouseOverEnabled: true
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].mouseOverEnabled;

  //Set
  $(".selector").igDataChart("option", "series",
  	[{
  		name: "series1",
  		type: "scatter",
  		xAxis: "xAxis",
  		yAxis: "yAxis",
  		xMemberPath: "Index",
  		yMemberPath: "Value1",
  		markerType: "automatic",
  		mouseOverEnabled: true
  	}]
  );


• name

  Type:

  string

  Default:

  null

  The unique identifier of the series.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].name;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      );


• negativeBrush

  Type:

  string

  Default:

  null

  Gets or sets the brush to use for negative portions of the series.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              negativeBrush: "red"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].negativeBrush;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              negativeBrush: "red"
          }]
      );


• openMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the open mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].openMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      );


• outline

  Type:

  string

  Default:

  null

  Gets or sets the brush to use for the outline of the series.
  Some series types, such as LineSeries, do not display outlines. Therefore, this property does not affect some charts.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              outline: "black"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].outline;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              outline: "black"
          }]
      );


• period

  Type:

  number

  Default:

  0

  Gets or sets the moving average period for the current AverageDirectionalIndexIndicator object.
  The typical, and initial, value for AverageDirectionalIndexIndicator periods is 14.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "averageDirectionalIndexIndicator",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              period: 7
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].period;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "averageDirectionalIndexIndicator",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              period: 7
          }]
      );


• progressiveLoad

  Type:

  bool

  Default:

  true

  Gets or sets whether to progressively load the data into the chart.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              markerType: "automatic",
              progressiveLoad: false
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].progressiveLoad;

  //Set
  $(".selector").igDataChart("option", "series",
  	[{
  		name: "series1",
  		type: "scatter",
  		xAxis: "xAxis",
  		yAxis: "yAxis",
  		xMemberPath: "Index",
  		yMemberPath: "Value1",
  		markerType: "automatic",
  		progressiveLoad: false
  	}]
  );


• radius

  Type:

  number

  Default:

  2

  Gets or sets the corner radius to use for the series, if applicable.

  Code Sample


            //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "angleAxis",
              type: "numericAngle"
          },
          {
              name: "radius",
              type: "numericRadius"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "polarScatter",
              angleAxis: "angleAxis",
              radius: "radius",
              angleMemberPath: "Index",
              radiusMemberPath: "Value1"
          }],
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].radius;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              title: "Sales",
              type: "polarScatter",
              angleAxis: "angleAxis",
              radius: "radius",
              angleMemberPath: "Index",
              radiusMemberPath: "Value1"
          }]
      );


• radiusAxis

  Type:

  string

  Default:

  null

  Gets the effective radius axis for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "angleAxis",
              type: "numericAngle"
          },
          {
              name: "radiusAxis",
              type: "numericRadius"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "polarScatter",
              angleAxis: "angleAxis",
              radiusAxis: "radiusAxis",
              angleMemberPath: "Index",
              radiusMemberPath: "Value1"
          }],
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].radiusAxis;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              title: "Sales",
              type: "polarScatter",
              angleAxis: "angleAxis",
              radiusAxis: "radiusAxis",
              angleMemberPath: "Index",
              radiusMemberPath: "Value1"
          }]
      );


• radiusMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the radius mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "angleAxis",
              type: "numericAngle"
          },
          {
              name: "radiusAxis",
              type: "numericRadius"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "polarScatter",
              angleAxis: "angleAxis",
              radiusAxis: "radiusAxis",
              angleMemberPath: "Index",
              radiusMemberPath: "Value1"
          }],
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].radiusMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              title: "Sales",
              type: "polarScatter",
              angleAxis: "angleAxis",
              radiusAxis: "radiusAxis",
              angleMemberPath: "Index",
              radiusMemberPath: "Value1"
          }]
      );


• radiusScale

  Type:

  object

  Default:

  null

  Gets or sets the radius size scale for the bubbles.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "bubble",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              radiusMemberPath: "Value2",
              fillMemberPath: "Value3",
              labelMemberPath: "Value2",
              radiusScale: {
                    minimumValue: 0,
                    maximumValue: 20,
                    isLogarithmic: "true",
                    logarithmicBase: 2
                }
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].radiusScale;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "bubble",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              radiusMemberPath: "Value2",
              fillMemberPath: "Value3",
              labelMemberPath: "Value2",
              radiusScale: {
                    type: "value",
                    brushes: ["red", "blue"],
                    minimumValue: 0,
                    maximumValue: 20
                }
          }]
      );


• radiusX

  Type:

  number

  Default:

  2.0

  Gets or sets the x-radius of the ellipse that is used to round the corners of the column.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          series: [{
              name: "series1",
              type: "column",
              radiusX: 5.5
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].radiusX;

  //Set
  $(".selector").igDataChart("option", "series",
      [{
              name: "series1",
              type: "column",
              radiusX: 5.5
      }]
  );


• radiusY

  Type:

  number

  Default:

  2.0

  Gets or sets the y-radius of the ellipse that is used to round the corners of the column.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          series: [{
              name: "series1",
              type: "column",
              radiusY: 5.5
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].radiusY;

  //Set
  $(".selector").igDataChart("option", "series",
      [{
              name: "series1",
              type: "column",
              radiusY: 5.5
      }]
  );


• remove

  Type:

  bool

  Default:

  false

  Set to true in order to have an existing series removed from the chart, by name.

  Code Sample

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              remove: true
          }]
      );


• resolution

  Type:

  number

  Default:

  1

  Gets or sets the current series object's rendering resolution.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              resolution: 3
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].resolution;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              resolution: 3
          }]
      );


• responseDataKey

  Type:

  string

  Default:

  null

  See $.ig.DataSource. Specifies the name of the property in which data records are held if the response is wrapped.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              responseDataKey: "Records",
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].responseDataKey;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              responseDataKey: "Records",
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close"
          }]
      );


• reverseLegendOrder

  Type:

  bool

  Default:

  false

  Sets whether the order of the fragment series should be reversed in the legend. Note: Reversing the legend order is only supported on stacked series.

  Code Sample


  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "stackedColumn",
              xAxis: "xAxis",
              yAxis: "yAxis",
              reverseLegendOrder: true,
              series: [{
                  name: "fragment1",
                  title: "fragment1",
              }, {
                  name: "fragment2",
                  title: "fragment2",
              }]
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].reverseLegendOrder;

  // Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              reverseLegendOrder: true
          }]
      );


• series

  Type:

  array

  Default:

  null

  Elements Type:

  Gets or sets the series for stacked charts. It should contain array of series objects. Each item in array should represent a series with and it may have most options supported by top-level series object, such as xAxis, yAxis, valueMemberPath, etc.

  Code Sample


  // Initialization
  $(".selector").igDataChart({
  	axes: [{
  		name: "xAxis",
  		type: "categoryX",
  		label: "Label",
  	}, {
  		name: "yAxis",
  		type: "numericY",
  	}],
  	series: [{
  		name: "series1",
  		type: "stackedColumn",
  		xAxis: "xAxis",
  		yAxis: "yAxis",
  		series: [{
  			name: "China",
  			type: "stackedFragment",
  			valueMemberPath: "China"
  		}, {
  			name: "United States",
  			type: "stackedFragment",
  			valueMemberPath: "UnitedStates"
  		}, {
  			name: "Russia",
  			type: "stackedFragment",
  			valueMemberPath: "Russia"
  		}, {
  			name: "Saudi Arabia",
  			type: "stackedFragment",
  			valueMemberPath: "SaudiArabia"
  		}, {
  			name: "Canada",
  			type: "stackedFragment",
  			valueMemberPath: "Canada"
  		}]
  	}]
  });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].series;

  // Set
  $(".selector").igDataChart("series", [{
  	name: "series1",
  	series: [{
  		name: "United States",
  		type: "stackedFragment",
  		valueMemberPath: "UnitedStates"
  	}]
  }]);


• shadowBlur

  Type:

  number

  Default:

  10

  Gets or sets the blur amount to use for the drop shadow.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              shadowBlur: 7
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].shadowBlur;

  // Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              shadowBlur: 7
          }]
      );


• shadowColor

  Type:

  object

  Default:

  rgba(95,95,95,0.5)

  Gets or sets the color to use for the drop shadow.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              shadowColor: "blue"
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].shadowColor;

  // Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              shadowColor: "blue"
          }]
      );


• shadowOffsetX

  Type:

  number

  Default:

  5

  Gets or sets the x offset amount to use for the drop shadow.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              shadowOffsetX: 10
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].shadowOffsetX;

  // Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              shadowOffsetX: 10
          }]
      );


• shadowOffsetY

  Type:

  number

  Default:

  5

  Gets or sets the y offset amount to use for the drop shadow.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              shadowOffsetY: 10
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].shadowOffsetY;

  // Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              shadowOffsetY: 10
          }]
      );


• shortPeriod

  Type:

  number

  Default:

  0

  Gets or sets the short moving average period for the current AbsoluteVolumeOscillatorIndicator object.
  The typical, and initial, value for short AVO periods is 10.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "absoluteVolumeOscillatorIndicator",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              shortPeriod: 7
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].shortPeriod;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "absoluteVolumeOscillatorIndicator",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              shortPeriod: 7
          }]
      );


• showTooltip

  Type:

  bool

  Default:

  false

  Whether the chart should render a tooltip.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              showTooltip: true,
              tooltipTemplate: "template"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].showTooltip;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              showTooltip: true,
              tooltipTemplate: "template"
          }]
      );


• skipUnknownValues

  Type:

  bool

  Default:

  false

  Gets or sets whether the hover layer should skip unknown values when trying to find the closest values.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "toolTipLayer1",
              type: "itemToolTipLayer",
              skipUnknownValues: true
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].skipUnknownValues;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "toolTipLayer1",
              type: "itemToolTipLayer",
              skipUnknownValues: true
          }]
      );


• splineType

  Type:

  enumeration

  Default:

  natural

  Gets or sets the type of spline to be rendered.

  Members

  • natural
  • Type:string
  • Calculates the spline using a natural spline calculation formula.
  • clamped
  • Type:string
  • Calculated the spline using a clamped spline calculation formula.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price Series 1",
              type: "spline",
              splineType: "clamped",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1"
          }]
      });

  //    Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].splineType;

  //    Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price Series 1",
              type: "spline",
              splineType: "clamped",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1"
          }]
      );


• targetAxis

  Type:

  string

  Default:

  null

  Gets or sets the name of the target axis for the layer, if desired. Setting the target axis will scope the layer to target just that axis.

  Code Sample


          //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "column",
                  name: "2005Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop2005"
              },            {
                  type: "line",
                  name: "1995Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop1995"
              },            {
                  type: "categoryHighlightLayer",
                  name: "catHighlightLayer",
                  title: "categoryHighlight",
                  useInterpolation: false,
                  transitionDuration: 500,
                  bandHighlightWidth: 50,
                  targetAxis: "PopulationAxis"

              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[2].targetAxis;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              type: "categoryHighlightLayer",
              name: "catHighlightLayer",
              title: "categoryHighlight",
              targetAxis: "PopulationAxis"
          }]
      );


• targetSeries

  Type:

  string

  Default:

  null

  Gets or sets the name of the target series for the layer, if desired. Setting the target series will scope the layer to target just that series.

  Code Sample


          //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "column",
                  name: "2005Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop2005"
              },            {
                  type: "line",
                  name: "1995Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop1995"
              },            {
                  type: "crosshairLayer",
                  name: "crosshairLayer",
                  title: "crosshair",
                  useInterpolation: false,
                  transitionDuration: 500,
                  targetSeries: "2005Population"
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[2].targetSeries;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "crosshairLayer",
              title: "crosshair",
              type: "crosshairLayer",
              targetSeries: "2005Population"
          }]
      );


• thickness

  Type:

  number

  Default:

  0

  Gets or sets the width of the current series object's line thickness.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price Series 1",
              type: "line",
              thickness: 5,
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1"
          }]
      });

  //    Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].thickness;

  //    Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price Series 1",
              type: "line",
              thickness: 5,
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1"
          }]
      );


• title

  Type:

  string

  Default:

  null

  Gets or sets the Title property.
  The legend item control is created according to the Title on-demand by
  the series object itself.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price Series 1",
              type: "line",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1"
          }]
      });

  //    Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].title;

  //    Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price Series 1",
              type: "line",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1"
          }]
      );


• tooltipPosition

  Type:

  enumeration

  Default:

  auto

  Gets or sets the Position to apply to the tooltip containers.

  Members

  • auto
  • Type:string
  • use an automatic position for the category tooltips.
  • outsideStart
  • Type:string
  • position the category tooltip at the outside start of the value axis.
  • insideStart
  • Type:string
  • position the category tooltip at the inside start of the value axis.
  • insideEnd
  • Type:string
  • position the category tooltip at the inside end of the value axis.
  • outsideEnd
  • Type:string
  • position the category tooltip at the outside end of the value axis.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "categoryToolTipLayer",
                  name: "catToolTipLayer",
                  title: "categoryToolTip",
                  toolTipPosition: "insideStart"

              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].toolTipPosition;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              type: "categoryToolTipLayer",
              name: "catToolTipLayer",
              title: "categoryToolTip",
              toolTipPosition: "insideStart"
          }]
      );


• tooltipTemplate

  Type:

  string

  Default:

  null

  The name of template or the template itself that chart tooltip will use to render.

  Code Sample

  <!--
  There are a number of properties available to the template related to the item or series it is used for.
    ${element}            -- The reference to tooltip DOM element.
    ${item}               -- The reference to current series item object.
    ${chart}              -- The reference to chart object.
    ${series}             -- The reference to current series object.
    ${actualItemBrush}    -- The item brush.
    ${actualSeriesBrush}  -- The series brush.
  -->
  <!-- Custom Tooltip Template -->
  <script id="usEnergyProductionTemplate" type="text/x-jquery-tmpl">
  	<div>
  		<span style="color: ${actualSeriesBrush}">US </span>
  		<span>${item.Year}</span><br />
  		Total Energy: <span style="font-weight: bold">${item.UnitedStates}</span>
  	</div>
  </script>

  //Initialization
  $(".selector").igDataChart({
          series: [{
              name: "series1",
              type: "column",
              showTooltip: true,
              tooltipTemplate: "usEnergyProductionTemplate"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].tooltipTemplate;

  //Set
  $(".selector").igDataChart("option", "series",
      [{
              name: "series1",
              type: "column",
              showTooltip: true,
              tooltipTemplate: "usEnergyProductionTemplate"
      }]
  );


• transitionDuration

  Type:

  number

  Default:

  0

  Gets or sets the duration of the current series's morph.

  Code Sample

  //    Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data1,
              title: "Price Series 1",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1",
              transitionDuration: 500
          }]
      });

  //    Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].transitionDuration;

  //    Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data1,
              title: "Price Series 1",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Item1",
              transitionDuration: 500
          }]
      );


• transitionEasingFunction

  Type:

  object

  Default:

  null

  Provides an easing function to use for the transitions. This should either be a well known name of an easing function (The only currently supported name is cubic), or it should be a function that takes a number and returns the output with the function applied.

  Code Sample


             //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
                  dataSource: data,
                  axes: [
                      {
                          name: "NameAxis",
                          type: "categoryX",
                          label: "CountryName"
                      },
                      {
                          name: "PopulationAxis",
                          type: "numericY",
                          minimumValue: 0,
                      }
                  ],
                  series: [
                      {
                          name: "2005Population",
                          type: "line",
                          title: "2005",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop2005",
                          isTransitionInEnabled: true,
                          transitionEasingFunction: "cubic"
                      }
                  ]
              });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].transitionEasingFunction;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "2005Population",
              type: "line",
              title: "2005",
              xAxis: "NameAxis",
              yAxis: "PopulationAxis",
              valueMemberPath: "Pop2005",
              isTransitionInEnabled: true,
              transitionEasingFunction: "cubic"
          }]
      );


• transitionInDuration

  Type:

  number

  Default:

  500

  Gets or sets the duration of the current series's transition in morph in milliseconds.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
                  dataSource: data,
                  axes: [
                      {
                          name: "NameAxis",
                          type: "categoryX",
                          label: "CountryName"
                      },
                      {
                          name: "PopulationAxis",
                          type: "numericY",
                          minimumValue: 0,
                      }
                  ],
                  series: [
                      {
                          name: "2005Population",
                          type: "line",
                          title: "2005",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop2005",
                          isTransitionInEnabled: true,
                          transitionInDuration: 500
                      }
                  ]
              });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].transitionInDuration;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "2005Population",
              type: "line",
              title: "2005",
              xAxis: "NameAxis",
              yAxis: "PopulationAxis",
              valueMemberPath: "Pop2005",
              isTransitionInEnabled: true,
              transitionInDuration: 500
          }]
      );


• transitionInMode

  Type:

  enumeration

  Default:

  auto

  Gets or sets the method to transition in the series. Note: Transitions are not currently supported for stacked series.

  Members

  • auto
  • Type:string
  • Series transitions in an automatically chosen way.
  • fromZero
  • Type:string
  • Series transitions in from the reference value of the value axis.
  • sweepFromLeft
  • Type:string
  • Series sweeps in from the left.
  • sweepFromRight
  • Type:string
  • Series sweeps in from the right.
  • sweepFromTop
  • Type:string
  • Series sweeps in from the top.
  • sweepFromBottom
  • Type:string
  • Series sweeps in from the bottom.
  • sweepFromCenter
  • Type:string
  • Series sweeps in from the center.
  • accordionFromLeft
  • Type:string
  • Series accordions in from the left.
  • accordionFromRight
  • Type:string
  • Series accordions in from the right.
  • accordionFromTop
  • Type:string
  • Series accordions in from the top.
  • accordionFromBottom
  • Type:string
  • Series accordions in from the bottom.
  • expand
  • Type:string
  • Series expands from the value midpoints.
  • sweepFromCategoryAxisMinimum
  • Type:string
  • Series sweeps in from the category axis minimum.
  • sweepFromCategoryAxisMaximum
  • Type:string
  • Series sweeps in from the category axis maximum.
  • sweepFromValueAxisMinimum
  • Type:string
  • Series sweeps in from the value axis minimum.
  • sweepFromValueAxisMaximum
  • Type:string
  • Series sweeps in from the value axis maximum.
  • accordionFromCategoryAxisMinimum
  • Type:string
  • Series accordions in from the category axis minimum.
  • accordionFromCategoryAxisMaximum
  • Type:string
  • Series accordions in from the category axis maximum.
  • accordionFromValueAxisMinimum
  • Type:string
  • Series accordions in from the value axis minimum.
  • accordionFromValueAxisMaximum
  • Type:string
  • Series accordions in from the value axis maximum.

  Code Sample


          //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
                  dataSource: data,
                  axes: [
                      {
                          name: "NameAxis",
                          type: "categoryX",
                          label: "CountryName"
                      },
                      {
                          name: "PopulationAxis",
                          type: "numericY",
                          minimumValue: 0,
                      }
                  ],
                  series: [
                      {
                          name: "2005Population",
                          type: "line",
                          title: "2005",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop2005",
                          isTransitionInEnabled: true,
                          transitionInMode: "sweepFromRight"
                      }
                  ]
              });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].isTransitionInMode;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "2005Population",
              type: "line",
              title: "2005",
              xAxis: "NameAxis",
              yAxis: "PopulationAxis",
              valueMemberPath: "Pop2005",
              isTransitionInEnabled: true,
              transitionInMode: "sweepFromRight"
          }]
      );

• transitionInSpeedType

  Type:

  enumeration

  Default:

  auto

  Gets or sets the speed to transition in the series data points.

  Members

  • auto
  • Type:string
  • A speed type is automatically selected.
  • normal
  • Type:string
  • All speeds are normal, data points will arrive at the same time.
  • valueScaled
  • Type:string
  • Data points will arrive later if their value is further from the start point.
  • indexScaled
  • Type:string
  • Data points will arrive later if their index is further from the axis origin.
  • random
  • Type:string
  • Data points will arrive at random times.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
                  dataSource: data,
                  axes: [
                      {
                          name: "NameAxis",
                          type: "categoryX",
                          label: "CountryName"
                      },
                      {
                          name: "PopulationAxis",
                          type: "numericY"
                      }
                  ],
                  series: [
                      {
                          name: "2005Population",
                          type: "line",
                          title: "2005",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop2005",
                          isTransitionInEnabled: true,
                          transitionInSpeedType: "indexScaled"
                      },
                      {
                          name: "1995Population",
                          type: "line",
                          title: "1995",
                          xAxis: "NameAxis",
                          yAxis: "PopulationAxis",
                          valueMemberPath: "Pop1995",
                          isTransitionInEnabled: true,
                          transitionInSpeedType: "indexScaled"
                      }
                  ]
              });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].transitionInSpeedType;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "2005Population",
              type: "line",
              title: "2005",
              xAxis: "NameAxis",
              yAxis: "PopulationAxis",
              valueMemberPath: "Pop2005",
              isTransitionInEnabled: true,
              transitionInSpeedType: "indexScaled"
          }]
      );



• trendLineBrush

  Type:

  string

  Default:

  null

  Gets or sets the brush to use to draw the trend line.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
      axes: [{
          name: "xAxis",
          type: "categoryX",
          dataSource: data,
          label: "Label"
      }, {
          name: "yAxis",
          type: "numericY"
      }],
      series: [{
          name: "series1",
          dataSource: data,
          title: "Price",
          type: "financial",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          trendLineType: "exponentialAverage",
          trendLineBrush: "grey"
      }]
  });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].trendLineBrush;

  // Set
  $(".selector").igDataChart("option", "series",
      [{
          name: "series1",
          dataSource: data,
          title: "Price",
          type: "financial",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          trendLineType: "exponentialAverage",
          trendLineBrush: "grey"
      }]
  );


• trendLinePeriod

  Type:

  number

  Default:

  7

  Gets or sets the moving average period for the current scatter series object.
  The typical, and initial, value for trend line period is 7.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
      axes: [{
          name: "xAxis",
          type: "categoryX",
          dataSource: data,
          label: "Label"
      }, {
          name: "yAxis",
          type: "numericY"
      }],
      series: [{
          name: "series1",
          dataSource: data,
          title: "Price",
          type: "financial",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          trendLineType: "simpleAverage",
          trendLinePeriod: 5
      }]
  });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].trendLinePeriod;

  //Set
  $(".selector").igDataChart("option", "series",
      [{
          name: "series1",
          dataSource: data,
          title: "Price",
          type: "financial",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          trendLineType: "simpleAverage",
          trendLinePeriod: 5
      }]
  );


• trendLineThickness

  Type:

  number

  Default:

  1.5

  Gets or sets the thickness of the current scatter series object's trend line.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
      axes: [{
          name: "xAxis",
          type: "categoryX",
          dataSource: data,
          label: "Label"
      }, {
          name: "yAxis",
          type: "numericY"
      }],
      series: [{
          name: "series1",
          dataSource: data,
          title: "Price",
          type: "financial",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          trendLineType: "simpleAverage",
          trendLineThickness: 3
      }]
  });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].trendLineThickness;

  //Set
  $(".selector").igDataChart("option", "series",
      [{
          name: "series1",
          dataSource: data,
          title: "Price",
          type: "financial",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          trendLineType: "simpleAverage",
          trendLineThickness: 3
      }]
  );


• trendLineType

  Type:

  enumeration

  Default:

  none

  Gets or sets the trend type for the current scatter series.

  Members

  • none
  • Type:string
  • No trendline should display.
  • linearFit
  • Type:string
  • Linear fit.
  • quadraticFit
  • Type:string
  • Quadratic polynomial fit.
  • cubicFit
  • Type:string
  • Cubic polynomial fit.
  • quarticFit
  • Type:string
  • Quartic polynomial fit.
  • quinticFit
  • Type:string
  • Quintic polynomial fit.
  • logarithmicFit
  • Type:string
  • Logarithmic fit.
  • exponentialFit
  • Type:string
  • Exponential fit.
  • powerLawFit
  • Type:string
  • Powerlaw fit.
  • simpleAverage
  • Type:string
  • Simple moving average.
  • exponentialAverage
  • Type:string
  • Exponential moving average.
  • modifiedAverage
  • Type:string
  • Modified moving average.
  • cumulativeAverage
  • Type:string
  • Cumulative moving average.
  • weightedAverage
  • Type:string
  • Weighted moving average.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
      axes: [{
          name: "xAxis",
          type: "categoryX",
          dataSource: data,
          label: "Label"
      }, {
          name: "yAxis",
          type: "numericY"
      }],
      series: [{
          name: "series1",
          dataSource: data,
          title: "Price",
          type: "financial",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          trendLineType: "simpleAverage"
      }]
  });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].trendLineType;

  //Set
  $(".selector").igDataChart("option", "series",
      [{
          name: "series1",
          dataSource: data,
          title: "Price",
          type: "financial",
          xAxis: "xAxis",
          yAxis: "yAxis",
          openMemberPath: "Open",
          highMemberPath: "High",
          lowMemberPath: "Low",
          closeMemberPath: "Close",
          trendLineType: "simpleAverage"
      }]
  );


• trendLineZIndex

  Type:

  number

  Default:

  1001

  Gets or sets the Z-Index of the trend line. Values greater than 1000 will result in the trend line being rendered in front of the series data.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              trendLineType: "simpleAverage",
              trendLineZIndex: 1200
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].trendLineZIndex;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              trendLineType: "simpleAverage",
              trendLineZIndex: 1200
          }]
      );


• type

  Type:

  enumeration

  Default:

  null

  Type of the series.

  Members

  • area
  • Type:string
  • Specify the series as Area series.
  • bar
  • Type:string
  • Specify the series as Bar series.
  • column
  • Type:string
  • Specify the series as Column series.
  • line
  • Type:string
  • Specify the series as Line series.
  • rangeArea
  • Type:string
  • Specify the series as Range Area series.
  • rangeColumn
  • Type:string
  • Specify the series as Range Column series.
  • splineArea
  • Type:string
  • Specify the series as Spline Area series.
  • spline
  • Type:string
  • Specify the series as Spline series.
  • stepArea
  • Type:string
  • Specify the series as Step Area series.
  • stepLine
  • Type:string
  • Specify the series as Step Line series.
  • waterfall
  • Type:string
  • Specify the series as Waterfall series.
  • financial
  • Type:string
  • Specify the series as Financial series.
  • typicalPriceIndicator
  • Type:string
  • Specify the series as Typical Price Indicator series.
  • polarArea
  • Type:string
  • Specify the series as Polar Area series.
  • polarLine
  • Type:string
  • Specify the series as Polar Line series.
  • polarScatter
  • Type:string
  • Specify the series as Polar Scatter series.
  • radialColumn
  • Type:string
  • Specify the series as Radial Column series.
  • radialLine
  • Type:string
  • Specify the series as Radial Line series.
  • radialPie
  • Type:string
  • Specify the series as Radial Pie series.
  • scatter
  • Type:string
  • Specify the series as Scatter series.
  • scatterLine
  • Type:string
  • Specify the series as Scatter Line series.
  • bubble
  • Type:string
  • Specify the series as Bubble series.
  • absoluteVolumeOscillatorIndicator
  • Type:string
  • Specify the series as Absolute Volume Oscillator Indicator series.
  • averageTrueRangeIndicator
  • Type:string
  • Specify the series as Average True Range Indicator series.
  • accumulationDistributionIndicator
  • Type:string
  • Specify the series as Accumulation Distribution Indicator series.
  • averageDirectionalIndexIndicator
  • Type:string
  • Specify the series as Average Directional Index Indicator series.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].type;


• unknownValuePlotting

  Type:

  enumeration

  Default:

  dontPlot

  Determines how unknown values will be plotted on the chart. Null and Double.NaN are two examples of unknown values.

  Members

  • linearInterpolate
  • Type:string
  • Plot the unknown value as the midpoint between surrounding known values using linear interpolation.
  • dontPlot
  • Type:string
  • Do not plot the unknown value on the chart.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              unknownValuePlotting: "linearInterpolate"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].unknownValuePlotting;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              unknownValuePlotting: "linearInterpolate"
          }]
      );


• useBruteForce

  Type:

  bool

  Default:

  false

  Gets or sets whether to use use brute force mode.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          series: [{
              name: "series1",
              type: "column",
  			useBruteForce: true
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].useBruteForce;

  //Set
  $(".selector").igDataChart("option", "series",
      [{
              name: "series1",
              type: "column",
  			useBruteForce: true
      }]
  );


• useCartesianInterpolation

  Type:

  bool

  Default:

  true

  Gets or sets whether Cartesian Interpolation should be used rather than Archimedian
  spiral based interpolation.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              unknownValuePlotting: "linearInterpolate",
              useCartesianInterpolation: false
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].useCartesianInterpolation;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              unknownValuePlotting: "linearInterpolate",
              useCartesianInterpolation: false
          }]
      );


• useHighMarkerFidelity

  Type:

  bool

  Default:

  false

  Sets or Gets whether to increase marker fidelity for extreme data shapes that have lots of Y variation over short X intervals.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              useHighMarkerFidelity: true
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].useHighMarkerFidelity;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1",
              useHighMarkerFidelity: true
          }]
      );


• useIndex

  Type:

  bool

  Default:

  false

  Sets if the current layer should take up a brush/ordering index in the series collection to derive its color automatically.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "categoryHighlightLayer",
                  name: "categoryHighlightLayer",
                  title: "categoryHighlight",
                  useIndex: "true"
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].useIndex;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              type: "categoryHighlightLayer",
              name: "categoryHighlightLayer",
              title: "categoryHighlight",
              useIndex: "true"
          }]
      );


• useInterpolation

  Type:

  bool

  Default:

  false

  Gets or sets whether the hover layer should use interpolation to position itself relative the closest values.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "column",
                  name: "2005Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop2005"
              },            {
                  type: "line",
                  name: "1995Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop1995"
              },            {
                  type: "crosshairLayer",
                  name: "crosshairLayer",
                  title: "crosshair",
                  useInterpolation: false,
                  transitionDuration: 500,
                  targetSeries: "2005Population",
                  horizontalLineVisibility: "visible"
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[2].useInterpolation;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "crosshairLayer",
              title: "crosshair",
              type: "crosshairLayer",
              useInterpolation: false
          }]
      );


• useLegend

  Type:

  bool

  Default:

  false

  Sets if the current layer should have an entry in the legend of the chart. By default annotation layers are not present in the legend.

  Code Sample


            //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  name: "crosshairLayer",
                  title: "crosshair",
                  type: "crosshairLayer",
                  useLegend: "true"
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].useLegend;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "crosshairLayer",
              title: "crosshair",
              type: "crosshairLayer",
              useLegend: "true"
          }]
      );


• useSingleShadow

  Type:

  bool

  Default:

  true

  Gets or sets whether drop shadow is applied to the whole series visual or to each of the individual shapes forming the series.

  Code Sample

  // Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              title: "Sales",
              type: "column",
              xAxis: "xAxis",
              yAxis: "yAxis",
              valueMemberPath: "Value1",
              useSingleShadow: false
          }]
      });

  // Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].useSingleShadow;

  // Set
  $(".selector").igDataChart("series",
          [{
              name: "series1",
              useSingleShadow: false
          }]
      );


• useSquareCutoffStyle

  Type:

  bool

  Default:

  false

  Gets or sets whether to use squares when halting a render traversal rather than the shape of the coalesced area.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          series: [{
              name: "series1",
              type: "column",
  			useSquareCutoffStyle: true
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].useSquareCutoffStyle;

  //Set
  $(".selector").igDataChart("option", "series",
      [{
              name: "series1",
              type: "column",
  			useSquareCutoffStyle: true
      }]
  );


• valueAxis

  Type:

  string

  Default:

  null

  Gets the effective value axis for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "angleAxis",
              type: "categoryAngle",
              label: "Label"
          }, {
              name: "radiusAxis",
              type: "numericRadius"
          }],
          series: [{
              name: "series1",
              title: 'Budget',
              type: "radialLine",
              angleAxis: "angleAxis",
              valueAxis: "radiusAxis",
              valueMemberPath: "Budget"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].valueAxis;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              title: 'Budget',
              type: "radialLine",
              angleAxis: "angleAxis",
              valueAxis: "radiusAxis",
              valueMemberPath: "Budget"
          }]
      );


• valueMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the item path that provides the values for the current series.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "angleAxis",
              type: "categoryAngle",
              label: "Label"
          }, {
              name: "radiusAxis",
              type: "numericRadius"
          }],
          series: [{
              name: "series1",
              title: 'Budget',
              type: "radialLine",
              angleAxis: "angleAxis",
              valueAxis: "radiusAxis",
              valueMemberPath: "Budget"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].valueMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              title: 'Budget',
              type: "radialLine",
              angleAxis: "angleAxis",
              valueAxis: "radiusAxis",
              valueMemberPath: "Budget"
          }]
      );


• verticalLineVisibility

  Type:

  enumeration

  Default:

  visible

  Gets or sets whether the vertical crosshair portion of the layer should be visible.

  Members

  • visible
  • Type:string
  • the vertical crosshair portion of the layer should be visible.
  • collapsed
  • Type:string
  • the vertical crosshair portion of the layer should not be visible.

  Code Sample


          //Initialization
  <script type="text/javascript">
      $(function () {
          $("#chart").igDataChart({
              dataSource: data,
              axes: [{
                  type: "categoryX",
                  name: "NameAxis",
                  label: "CountryName",
              }, {
                  type: "numericY",
                  name: "PopulationAxis",
              }],
              series: [            {
                  type: "column",
                  name: "2005Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop2005"
              },            {
                  type: "line",
                  name: "1995Population",
                  xAxis: "NameAxis",
                  yAxis: "PopulationAxis",
                  valueMemberPath: "Pop1995"
              },            {
                  type: "crosshairLayer",
                  name: "crosshairLayer",
                  title: "crosshair",
                  useInterpolation: false,
                  transitionDuration: 500,
                  targetSeries: "2005Population",
                  verticalLineVisibility: "visible"
              }
              ]
          });
      });
  </script>

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[2].verticalLineVisibilty;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "crosshairLayer",
              title: "crosshair",
              type: "crosshairLayer",
              verticalLineVisiblity: "visible"
          }]
      );


• volumeMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the volume mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "categoryX",
              dataSource: data,
              label: "Label"
          },
          {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              volumeMemberPath: "Volume"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].volumeMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              dataSource: data,
              title: "Price",
              type: "financial",
              xAxis: "xAxis",
              yAxis: "yAxis",
              openMemberPath: "Open",
              highMemberPath: "High",
              lowMemberPath: "Low",
              closeMemberPath: "Close",
              volumeMemberPath: "Volume"
          }]
      );


• xAxis

  Type:

  string

  Default:

  null

  Gets or sets the effective x-axis for the current object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].xAxis;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      );


• xMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the value mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].xMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      );


• yAxis

  Type:

  string

  Default:

  null

  Gets or sets the effective y-axis for the current object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].yAxis;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      );


• yMemberPath

  Type:

  string

  Default:

  null

  Gets or sets the value mapping property for the current series object.

  Code Sample

  //Initialization
  $(".selector").igDataChart({
          axes: [{
              name: "xAxis",
              type: "numericX"
          }, {
              name: "yAxis",
              type: "numericY"
          }],
          series: [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      });

  //Get
  var series = $(".selector").igDataChart("option", "series");
  series[0].yMemberPath;

  //Set
  $(".selector").igDataChart("option", "series",
          [{
              name: "series1",
              type: "scatter",
              xAxis: "xAxis",
              yAxis: "yAxis",
              xMemberPath: "Index",
              yMemberPath: "Value1"
          }]
      );


To set both dimensions of the chart simultaneously an object with a width and height property can be provided.

//Initialize
$(".selector").igDataChart({
    size: { width: 450, height: 450 }
});

//Get
var size = $(".selector").igDataChart("option", "size");
//Set
var size = $(".selector").igDataChart("option", "size", { width: 450, height: 450 });


Gets or sets the template to use for square markers on the chart.
Defines the marker template used for
series with a marker type of square.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    squareMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


The subtitle to display for the component.


    //	Initialization
		$(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        subtitle:"Results over a two year period",
        subtitleTextColor: "blue",
        subtitleTextStyle: "16pt Verdona"
    });

		//Get
		var subtitleValue = $(".selector").igDataChart("option", "subtitle");

		//Set
		$(".selector").igDataChart("option", "subtitle", "Results over a two year period");


The bottom margin to use for the subtitle.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        subtitle:"Results over a two year period",
        subtitleTextColor: "blue",
        subtitleTextStyle: "16pt Verdona",
        subtitleBottomMargin: 10
    });

		//Get
		var subtitleBottomMarginValue = $(".selector").igDataChart("option", "subtitleBottomMargin");

		//Set
		$(".selector").igDataChart("option", "subtitleBottomMargin", 10);


the horizontal alignment to use for the subtitle.


       //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        subtitle:"Results over a two year period",
        subtitleTextColor: "blue",
        subtitleTextStyle: "16pt Verdona",
        subtitleHorizontalAlignment: "center"
      });

		//Get
		var subtitleHorizontalAlignmentValue = $(".selector").igDataChart("option", "subtitleHorizontalAlignment");

		//Set
		$(".selector").igDataChart("option", "subtitleHorizontalAlignment", "center");



The left margin to use for the subtitle.


     //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        subtitle:"Results over a two year period",
        subtitleTextColor: "blue",
        subtitleTextStyle: "16pt Verdona",
        subtitleLeftMargin: 10
    });

		//Get
		var subtitleLeftMarginValue = $(".selector").igDataChart("option", "subtitleLeftMargin");

		//Set
		$(".selector").igDataChart("option", "subtitleLeftMargin", 10);


The right margin to use for the subtitle.


    //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        subtitle:"Results over a two year period",
        subtitleTextColor: "blue",
        subtitleTextStyle: "16pt Verdona",
        subtitleRightMargin: 10
    });

		//Get
		var subtitleRightMarginValue = $(".selector").igDataChart("option", "subtitleRightMargin");

		//Set
		$(".selector").igDataChart("option", "subtitleRightMargin", 10);


The color to use for the subtitle.


    //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        subtitle:"Results over a two year period",
        subtitleTextColor: "blue",
        subtitleTextStyle: "16pt Verdona",
        subtitleLeftMargin: 10
    });

		//Get
		var subtitleTextColorValue = $(".selector").igDataChart("option", "subtitleTextColor");

		//Set
		$(".selector").igDataChart("option", "subtitleTextColor", "blue");


The css font property to use for the title.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        subtitle:"Results over a two year period",
        subtitleTextColor: "blue",
        subtitleTextStyle: "16pt Verdona",
        subtitleLeftMargin: 10
    });

		//Get
		var subtitleTextStyleValue = $(".selector").igDataChart("option", "subtitleTextStyle");

		//Set
		$(".selector").igDataChart("option", "subtitleTextStyle", "16pt Verdona");


The top margin to use for the subtitle.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        subtitle:"Results over a two year period",
        subtitleTextColor: "blue",
        subtitleTextStyle: "16pt Verdona",
        subtitleTopMargin: 10
    });

		//Get
		var subtitleTopMarginValue = $(".selector").igDataChart("option", "subtitleTopMargin");

		//Set
		$(".selector").igDataChart("option", "subtitleTopMargin", 10);

The channel name to use to sync this chart with other charts.


//Initialize
$(".selector").igDataChart({
    syncChannel: "syncCharts"
});

//Get
var syncChannel = $(".selector").igDataChart("option", "syncChannel");
//Set
var syncChannel = $(".selector").igDataChart("option", "syncChannel", "syncCharts");


Whether the chart should be synchronized horizontally.

		//	Initialization
		$(".selector").igDataChart({
                synchronizeHorizontally: false
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "synchronizeHorizontally");

		//	Set
		$(".selector").igDataChart("option", "synchronizeHorizontally", false);


Whether the chart should be synchronized vertically.

		//	Initialization
		$(".selector").igDataChart({
                synchronizeVertically: false
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "synchronizeVertically");

		//	Set
		$(".selector").igDataChart("option", "synchronizeVertically", false);


Gets or sets the template to use for tetragram markers on the chart.
Defines the marker template used for
series with a marker type of tetragram.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    tetragramMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


The swatch used to style this widget.

//Initialize
$(".selector").igDataChart({
    theme: "metro"
});

//Get
var theme = $(".selector").igDataChart("option", "theme");


The title to display for the component.


       //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona"
      });

		  //Get
		  var titleValue = $(".selector").igDataChart("option", "title");

		  //Set
		  $(".selector").igDataChart("option", "title", "Energy Use Per Country");


The bottom margin to use for the title.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        titleBottomMargin: 10
      });

		  //Get
		  var titleBottomMarginValue = $(".selector").igDataChart("option", "titleBottomMargin");

		  //Set
		  $(".selector").igDataChart("option", "titleBottomMargin", 10);


the horizontal alignment to use for the title.


       //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        titleHorizontalAlignment: "center"
      });

		  //Get
		  var titleHorizontalAlignmentValue = $(".selector").igDataChart("option", "titleHorizontalAlignment");

		  //Set
		  $(".selector").igDataChart("option", "titleHorizontalAlignment", "center");


The left margin to use for the title.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        titleLeftMargin: 10
      });

		  //Get
		  var titleLeftMarginValue = $(".selector").igDataChart("option", "titleLeftMargin");

		  //Set
		  $(".selector").igDataChart("option", "titleLeftMargin", 10);


The right margin to use for the title.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        titleRightMargin: 10
      });

		  //Get
		  var titleRightMarginValue = $(".selector").igDataChart("option", "titleRightMargin");

		  //Set
		  $(".selector").igDataChart("option", "titleRightMargin", 10);


The color to use for the title.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        titleBottomMargin: 10
      });

		  //Get
		  var titleTextColorValue = $(".selector").igDataChart("option", "titleTextColor");

		  //Set
		  $(".selector").igDataChart("option", "titleTextColor", "red");


The css font property to use for the title.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        titleBottomMargin: 10
      });

		  //Get
		  var titleTextStyleValue = $(".selector").igDataChart("option", "titleTextStyle");

		  //Set
		  $(".selector").igDataChart("option", "titleTextStyle", "24pt Verdona");


The top margin to use for the title.


      //	Initialization
		  $(".selector").igDataChart({
        title: "Energy Use Per Country",
        titleTextColor: "red",
        titleTextStyle: "24pt Verdona",
        titleTopMargin: 10
      });

		  //Get
		  var titleTopMarginValue = $(".selector").igDataChart("option", "titleTopMargin");

		  //Set
		  $(".selector").igDataChart("option", "titleTopMargin", 10);


Sets or gets the top margin to use around the chart content in the canvas.


        //Initialize
        $(".selector").igDataChart({
            topMargin : 20
        });

        //Get
        var margin = $(".selector").igDataChart("option", "topMargin");

        //Set
        $(".selector").igDataChart("option", "topMargin", 20);

Gets or sets the template to use for triangle markers on the chart.
Defines the marker template used for
series with a marker type of triangle.
The provided object should have properties called render and optionally measure. See definition for option: legendItemBadgeTemplate.

//Initialize
$(".selector").igDataChart({
    triangleMarkerTemplate: {
        measure: function(measureInfo) {
            measureInfo.context;    // either a DOM element or a CanvasContext2D depending on the particular template scenario
            measureInfo.width;      // if value is present, specifies the available width, user may set to desired width for content
            measureInfo.height;     // if value is present, specifies the available height, user may set to desired height for content
            measureInfo.isConstant; // user should set to true if desired with and height will always be the same for this template
            measureInfo.data;       // if present, represents the contextual data for this template]
        },
        render: function (renderInfo) {
            renderInfo.context;            //    either a DOM element or a CanvasContext2D depending on the particular template scenario
            renderInfo.xPosition;          //    if present, specifies the x position at which to render the content
            renderInfo.yPosition;          //    if present, specifies the y position at which to render the content
            renderInfo.availableWidth;     //    if present, specifies the available width in which to render the content
            renderInfo.availableHeight;    //    if present, specifies the available height in which to render the content
            renderInfo.data;               //    if present, specifies the data that is in context for this content
            renderInfo.isHitTestRender;    //    if true, indicates that this is a special render pass for hit testing, in which case the brushes from the data should be used
        }
    }
});


Sets whether the series viewer should use cached tiles during zooms rather than the default live content.

		//	Initialization
		$(".selector").igDataChart({
                useTiledZooming: true
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "useTiledZooming");

		//	Set
		$(".selector").igDataChart("option", "useTiledZooming", true);


Gets or sets the current Chart's vertical zoomability.

		//	Initialization
		$(".selector").igDataChart({
                verticalZoomable: true
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "verticalZoomable");

		//	Set
		$(".selector").igDataChart("option", "verticalZoomable", true);


The width of the chart. It can be set as a number in pixels, string (px) or percentage (%).

// Initialization
$(".selector").igDataChart({
    width: "700px"
});

// Get
var width = $(".selector").igDataChart("option", "width");

// Set
$(".selector").igDataChart("option", "width", "700px");


A number between 0 and 1 determining the position of the horizontal scroll.
This property is effectively a shortcut to the X position of the WindowRect property.

		//	Initialization
		$(".selector").igDataChart({
                windowPositionHorizontal: 0.25
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "windowPositionHorizontal");

		//	Set
		$(".selector").igDataChart("option", "windowPositionHorizontal", 0.25);


A number between 0 and 1 determining the position of the vertical scroll.
This property is effectively a shortcut to the Y position of the WindowRect property.

		//	Initialization
		$(".selector").igDataChart({
                windowPositionVertical: 0.25
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "windowPositionVertical");

		//	Set
		$(".selector").igDataChart("option", "windowPositionVertical", 0.25);


A rectangle representing the portion of the chart currently in view.
A rectangle at X=0, Y=0 with a Height and Width of 1 implies the entire plotting area is in view. A Height and Width of .5 would imply that the view is halfway zoomed in.
The provided object should have numeric properties called left, top, width and height.

      //	Initialization
      $(".selector").igDataChart({
        windowRect:
	        {
		        left: 0,
		        top: 0,
		        width: 0.5,
		        height: 0.5
	        }
      });

      //	Get
      var opValue = $(".selector").igDataChart("option", "windowRect");

      //	Set
      $(".selector").igDataChart("option", "windowRect",
        {
          left: 0,
          top: 0,
          width: 0.5,
          height: 0.5
      });


Sets or gets the minimum width that the window rect is allowed to reach before being clamped.
Decrease this value if you want to allow for further zooming into the viewer.
If this value is lowered too much it can cause graphical corruption due to floating point arithmetic inaccuracy.

// Initialization
$(".selector").igDataChart({
    windowRectMinWidth: 0.5
});

// Get
var windowRectMinWidth = $(".selector").igDataChart("option", "windowRectMinWidth");

// Set
$(".selector").igDataChart("option", "windowRectMinWidth", 0.5);


The response to user panning and zooming: whether to update the view immediately while the user action is happening, or to defer the update to after the user action is complete. The user action will be an action such as a mouse drag which causes panning and/or zooming to occur.

		//	Initialization
		$(".selector").igDataChart({
                windowResponse: "immediate"
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "windowResponse");

		//	Set
		$(".selector").igDataChart("option", "windowResponse", "immediate");


A number between 0 and 1 determining the scale of the horizontal zoom.
This property is effectively a shortcut to the Width of the WindowRect property.

		//	Initialization
		$(".selector").igDataChart({
                windowScaleHorizontal: 0.5
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "windowScaleHorizontal");

		//	Set
		$(".selector").igDataChart("option", "windowScaleHorizontal", 0.5);


A number between 0 and 1 determining the scale of the vertical zoom.
This property is effectively a shortcut to the Height of the WindowRect property.

		//	Initialization
		$(".selector").igDataChart({
                windowScaleVertical: 0.5
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "windowScaleVertical");

		//	Set
		$(".selector").igDataChart("option", "windowScaleVertical", 0.5);


Sets the maximum number of zoom tiles that the series viewer should cache while in tiled zooming mode.

		//	Initialization
		$(".selector").igDataChart({
                zoomTileCacheSize: 30
            });

		//	Get
		var opValue = $(".selector").igDataChart("option", "zoomTileCacheSize");

		//	Set
		$(".selector").igDataChart("option", "zoomTileCacheSize", 30);
