Tile Manager - Leading Tile

This sample demonstrates instantiating the Tile Manager on existing markup in a container with a configuration that defines a leading tile.

Infragistics Car Dealership

Choose a car brand to browse

2013 LSL AMG
error
  • Price: $199,500 – $206,000
  • 0-100 in 3.8 seconds
  • Top speed: 317 km/h
2013 363 AMG
error
  • Price: $57,130 – $61,430
  • 0-60 in 4.4 seconds
  • Top speed: 250 km/h
2013 T350
error
  • Price: $47,542 - $51,120
  • 4MATIC All Wheel Drive
  • 0-60 in 5.5 seconds
  • 3.5l v6 engine
2013 500S
error
  • Price: $92,350 – $212,000
  • Night View Assist
  • Parking Distance Control
2013 M350L
error
  • Price: $47,681 - $51,270
  • 3.0L BlueTEC turbodiesel v6 engine
  • 4MATIC All Wheel Drive
  • Highway fuel efficiency of 28 mpg
2013 CSL
error
  • Price: $74,500 - $84,556
  • 4.6L v8 engine
  • 0-60 in 5.05 seconds
© Infragistics | Help and API docs

This sample is designed for a larger screen size.

On mobile, try rotating your screen, view full size, or email to another device.

The leading tile swaps with the rest of the tiles upon expanding.

Code View

Copy to Clipboard
<!DOCTYPE html>
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
    <title></title>
    <!-- Ignite UI for jQuery Required Combined CSS Files -->
    <link href="http://cdn-na.infragistics.com/igniteui/2024.2/latest/css/themes/infragistics/infragistics.theme.css" rel="stylesheet" />
    <link href="http://cdn-na.infragistics.com/igniteui/2024.2/latest/css/structure/infragistics.css" rel="stylesheet" />

    <!-- Modernizr/jQuery/jQuery UI -->
    <script src="http://ajax.aspnetcdn.com/ajax/modernizr/modernizr-2.8.3.js"></script>
    <script src="http://code.jquery.com/jquery-1.11.3.min.js"></script>
    <script src="http://code.jquery.com/ui/1.11.1/jquery-ui.min.js"></script>

    <!-- Ignite UI for jQuery Required Combined JavaScript Files -->
    <script src="http://cdn-na.infragistics.com/igniteui/2024.2/latest/js/infragistics.core.js"></script>
    <script src="http://cdn-na.infragistics.com/igniteui/2024.2/latest/js/infragistics.lob.js"></script>
</head>
<body>
    <style type="text/css">

        body {
            font-family: 'Segoe UI', 'Arial', 'Helvetica', 'sans-serif';
        }

        ul {
            text-decoration: none;
            padding: 0;
            margin: 0;
            list-style: none;
        }

        .ui-igtile-maximized .ui-igtile-inner-container {overflow: hidden;}


        #car-tabs {
            margin: auto;
        }

        .dashboard {
            font-size: 0.85em!important;
            position: relative;
            height: 660px;
        }

            .dashboard img {
                width: 100%;
            }

            .dashboard figure {
                margin:0;
            }

            .dashboard figcaption {
                font-size: 1.1em;
                background-color: #454545;
                color: #fff;
                padding: 10px 0 10px 10px;
            }

            .dashboard .ui-igtile-maximized  figcaption {
                background-color: #2cbdf9;
                -webkit-transition:0.5s;
            }

                .dashboard div ul {
                    border: 1px solid #ececec;
                    padding: 5px 5px 10px 5px;
                    -webkit-transition:0.5s;
                }

                    .dashboard div ul li:nth-child(n+2):before {
                        content: "• ";
                        color: #2cbdf9;
                    }

                    .dashboard div ul li:first-child {
                        color: #2cbdf9;
                    }

        #car-tabs.ui-tabs .ui-tabs-panel, #car-tabs.ui-tabs-nav, #car-tabs.ui-tabs .ui-tabs-nav li.ui-state-default {
            border: none;
            padding: 0;
        }

        #car-tabs.ui-tabs .ui-tabs-nav li.ui-state-active a {
            background-color: #2cbdf9!important;

        }

        #car-tabs.ui-tabs .ui-tabs-nav li.ui-state-default a {
            background-color: #95defc;
        }

        #car-tabs.ui-tabs .ui-tabs-nav li.ui-state-hover a {
            background-color: #6bd1fb;
        }

        #car-tabs.ui-tabs-anchor {
            text-shadow: none;
            color: #fff!important;
        }

        #car-tabs.ui-tabs-anchor:hover {
            text-decoration: underline;
        }

        #car-tabs.ui-tabs {
            border-radius: 0;
        }

        .sample-footer {
            margin-top: 10px;
            height: 80px;
            line-height: 75px;
            text-align: center;
            width: 100%;
            background-color: #44acd6;
        }
            .sample-footer a {
                color: #fff;
                vertical-align: middle;
            }

        .sample-header {
            height: 60px;
            line-height: 75px;
            width: 100%;
            background-color: #44acd6;
        }

        h1.hOne {
            margin: 0;
            clear: none;
            float: none;
            font-size: 2em;
        }

        @media all and (max-width: 430px) {
            #car-tabs.ui-tabs-nav li {
                font-size: 16px;
            }

            /*.sample-page #sample {
                margin-left: 0;
                margin-right: 0;
            }*/
        }
    </style>
    <h1 class="hOne">Infragistics Car Dealership</h1>
    <h3>Choose a car brand to browse</h3>
    <div id="car-tabs">
        <ul>
            <li><a href="#magarcedes">Magarcedes</a></li>
            <li><a href="#hoida">Hoida</a></li>
            <li><a href="#paushe">Paushe</a></li>
        </ul>
        <div id="magarcedes" class="dashboard">
            <div>
                <figure>
                    <figcaption>2013 LSL AMG</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_139519967.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $199,500 &ndash; $206,000</li>
                    <li>0-100 in 3.8 seconds</li>
                    <li>Top speed: 317 km/h</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 363 AMG</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_38284540.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $57,130 &ndash; $61,430</li>
                    <li>0-60 in 4.4 seconds</li>
                    <li>Top speed: 250 km/h</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 T350</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_25369924.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $47,542 - $51,120</li>
                    <li>4MATIC All Wheel Drive</li>
                    <li>0-60 in 5.5 seconds</li>
                    <li>3.5l v6 engine</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 500S</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_4417342.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $92,350 &ndash; $212,000</li>
                    <li>Night View Assist</li>
                    <li>Parking Distance Control</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 M350L</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_4028761.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $47,681 - $51,270</li>
                    <li>3.0L BlueTEC turbodiesel v6 engine</li>
                    <li>4MATIC All Wheel Drive</li>
                    <li>Highway fuel efficiency of 28 mpg</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 CSL</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_2564520.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $74,500 - $84,556</li>
                    <li>4.6L v8 engine</li>
                    <li>0-60 in 5.05 seconds</li>
                </ul>
            </div>
        </div>
        <div id="hoida" class="dashboard">
            <div>
                <figure>
                    <figcaption>2013 Candy</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_57034834.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $21,661 - $29,404</li>
                    <li>Gas I4 2.5L engine</li>
                    <li>Highway fuel efficiency of 35 mpg</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 RA4V 4WD</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_117299389.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $23,301 - $28,232</li>
                    <li>All Wheel Drive</li>
                    <li>Highway fuel efficiency of 29 mpg</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 Coralla</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_32589022.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $16,191 - $20,297</li>
                    <li>Gas I4 1.8L engine</li>
                    <li>Highway fuel efficiency of 34 mpg</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 Pruis C</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_134383163.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $19,058 - $23,163</li>
                    <li>Gas/Electric I4 1.5L engine</li>
                    <li>Highway fuel efficiency of 46 mpg</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 Cruiser</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_60821281.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $73,676 - $73,676</li>
                    <li>Gas V8 5.7L engine</li>
                    <li>All Wheel Drive</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 TLC</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_27395866.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $25,566 - $47,651</li>
                    <li>Gas V8 5.7L engine</li>
                    <li>Highway fuel efficiency of 17 mpg</li>
                </ul>
            </div>
        </div>
        <div id="paushe" class="dashboard">
            <div>
                <figure>
                    <figcaption>2013 CST</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_38288989.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $39,095 - $59,090</li>
                    <li>Available All Wheel Drive</li>
                    <li>Available touch-screen glide-up navigation with voice recognition</li>
                    <li>Leather seating surfaces</li>
                    <li>Adaptive Remote Start</li>
                </ul>
                <!--<p>Every detail of the 2013 CST Sport Sedan was designed for driving enthusiasts. A direct-injection 3.0L V6 engine, fine-tuned suspension, and hand-cut-and-sewn accents deliver power, agility and luxury.</p>-->
            </div>
            <div>
                <figure>
                    <figcaption>2013 CST-V</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_32949850.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $64,515 &ndash; $74,770</li>
                    <li>0-100 in 4.0 seconds</li>
                    <li>G-meter measures lateral acceleration</li>
                </ul>
                <!--<p>The 2013 Cadillac CST-V Coupe, it’s pure adrenaline on wheels. From the world’s fastest family of production cars comes a coupe that satisfies more than just driving enthusiasts, it inspires true automotive fanatics. A complete package of performance, styling and capability is achieved through the 556 HP V8 engine, the aggressive styling of its aerodynamic physique and the constant traction of revolutionary dual-mode Magnetic Ride Control, which reads the road up to 1,000 times per second.</p>-->
            </div>
            <div>
                <figure>
                    <figcaption>2013 ECS</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_7391134.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $63,170 - $82,875</li>
                    <li>Heated and cooled front seats</li>
                    <li>Available Magnetic Ride Control suspension system</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 AST</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_23082346.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $39,095 - $59,090</li>
                    <li>Available all-new 272 HP 2.0L turbocharged engine</li>
                    <li>Available navigation</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 SXR Crossover</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_134383139.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $37,330 - $58,220</li>
                    <li>Available $$(UltraView) sunroof</li>
                    <li>Available All Wheel Drive</li>
                </ul>
            </div>
            <div>
                <figure>
                    <figcaption>2013 CST-V Wagon</figcaption>
                    <img src="/images/samples/tile-manager/car-dealership/shutterstock_117299326.jpg" alt="error" />
                </figure>
                <ul>
                    <li>Price: $64,515 - $75,345</li>
                    <li>Power liftgate with memory height</li>
                    <li>Rearview backup camera</li>
                </ul>
            </div>
        </div>
    </div>
    <div class="sample-footer">
        <a class="float-left" href="https://www.infragistics.com">&copy; Infragistics</a>
        <span style="color: #FFF">   |    </span>
        <a class="float-left" href="https://help.infragistics.com">Help and API docs</a>
    </div>
    <script type="text/javascript">
        var activated = [false, false, false, false],
            optionsWide = {
                columnWidth: 210,
                columnHeight: 210,
                marginLeft: 10,
                marginTop: 10,
                items: [
                    { rowIndex: 0, colIndex: 0, rowSpan: 2, colSpan: 2 },
                    { rowIndex: 0, colIndex: 2, rowSpan: 1, colSpan: 1 },
                    { rowIndex: 1, colIndex: 2, rowSpan: 1, colSpan: 1 },
                    { rowIndex: 2, colIndex: 0, rowSpan: 1, colSpan: 1 },
                    { rowIndex: 2, colIndex: 1, rowSpan: 1, colSpan: 1 },
                    { rowIndex: 2, colIndex: 2, rowSpan: 1, colSpan: 1 }
                ],
                maximizedTileIndex: 0,
                minimizedState: ':not(ul)'
            },
            optionsPhone = {
                columnWidth: 125,
                columnHeight: 160,
                marginLeft: 5,
                marginTop: 5,
                items: [
                    { rowIndex: 0, colIndex: 0, rowSpan: 2, colSpan: 2 },
                    { rowIndex: 0, colIndex: 2, rowSpan: 1, colSpan: 1 },
                    { rowIndex: 1, colIndex: 2, rowSpan: 1, colSpan: 1 },
                    { rowIndex: 2, colIndex: 0, rowSpan: 1, colSpan: 1 },
                    { rowIndex: 2, colIndex: 1, rowSpan: 1, colSpan: 1 },
                    { rowIndex: 2, colIndex: 2, rowSpan: 1, colSpan: 1 }
                ],
                maximizedTileIndex: 0,
                minimizedState: ':not(ul)'
            },
            options;
        $(function () {
            $('#car-tabs').tabs({
                activate: function (event, ui) {
                    var index = ui.newTab.index();
                    if (!activated[index]) {
                        ui.newPanel.igTileManager(options);
                        activated[index] = true;
                    } else {
                        ui.newPanel.igTileManager('reflow');
                    }
                }
            });
            if ($(window).width() > 430) {
                options = optionsWide;
            } else {
                options = optionsPhone;
            }
            $('#magarcedes').igTileManager(options);
            activated[0] = true;
        });
    </script>
</body>
</html>
